Ubiquiti Unifi USW-Pro-XG-24-PoE 26-Port 25G L3 Managed Etherlighting PoE Switch (720W) - SFP28 x2, 10GbE PoE+++ x16, 2.5GbE PoE+++ x8

PB Tech price

NZD $ 3,742 .35

$ 3,742 .35

Out of stock

Ubiquiti Unifi USW-Pro-XG-24-PoE 26-Port 25G L3 Managed Etherlighting PoE Switch (720W) - SFP28 x2, 10GbE PoE+++ x16, 2.5GbE PoE+++ x8

Brand: Ubiquiti
MPN: USW-Pro-XG-24-PoE
Part #: SWHUBI2424
UPC:

PB Tech price

NZD $ 3,742 .35

Out of stock

Delivery: Out of stock

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Ubiquiti
MPN: USW-Pro-XG-24-PoE
Part #: SWHUBI2424
UPC:

Be the first to review this product

10 Gigabit Ports

Not Specified

10 Gigabit

Not Specified

Form Factor

Not Specified

Management Level

Not Specified

Number of Ports

8 Ports

PoE Ports

7 Ports

PoE Budget

210 Watts

View full specs

Returns & Warranty Bulk Quote Print Page

Features

Professional-grade, 24-port Layer 3 Etherlighting™ PoE+++ switch with (16) 10 GbE, (8) 2.5 GbE, and (2) 25G SFP28 ports.

Specifications

Performance

Switching Capacity

460 Gbps

Total Non-Blocking Throughput

230 Gbps

Forwarding Rate

342 Mpps

Supported VLANs

1,000

MAC Address Table Size

128,000

L3 Table Size

ARP Entries

128,000

IPv4 Routes

256,000

Packet Buffer Size

8 MB

Layer 3 Features

DHCP Server (Local Networks)

Yes

DHCP Relay

Yes

Inter-VLAN Routing (Local Networks)

Yes

Static Routing (Local Networks)

Yes

Layer 2 Features

LACP Port Aggregation

Yes

STP & RSTP

Yes

QoS (DSCP)

Yes

Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)

Yes

Advanced IGMP Configuration (Querier, Fast Leave, Router Port)

Yes

IGMP Snooping

Yes

802.1X Control

Yes

MAC-Based ACLs & Device Isolation

Yes

DHCP Snooping & Guarding

Yes

Egress Rate Limit

Yes

Flow Control

Yes

Storm Control

Yes

Multicast & Broadcast Rate Limiting

Yes

MAC Address Blocking

Yes

IP-Based ACLs & Network Isolation

Yes

MAC-Based Port Restriction

Yes

Port Isolation

Yes

Port Mirroring

Yes

Jumbo Frames

Yes

LLDP-MED

Yes

Voice VLAN

Yes

Loop Protection

Yes

Hardware

PoE Ports

PoE+++
24

Max. PoE Wattage per Port by PSE

PoE
15.4W
PoE+
30W
PoE++
60W
PoE+++
90W

Max. Power Consumption

150W (Excluding PoE Output)
870W (Including PoE Output)

Power Method

(1) Universal input, 100-240V AC, 50/60 Hz
(1) USP RPS DC input

Power Input Method

AC input

Power Supply

AC/DC, internal, 870W

Supported Voltage Range

100-240V AC

Management

Ethernet

Weight

Without mounting brackets: 7.9 kg (17.4 lb)
With mounting brackets: 8 kg (17.6 lb)

Enclosure Material

SGCC steel

Mount Material

SGCC steel

Supported Rack Depth

482.6 mm (19") four-post racks

LCM Display

1.3" touchscreen

ESD/EMP Protection

Air: ± 30kV, contact: ± 20kV

Ambient Operating Temperature

-5 to 40° C (23 to 104° F)

Ambient Operating Humidity

10 to 90% noncondensing

Etherlighting™

Ethernet

Yes

SFP28

Yes

LEDs

RPS

Yes

NDAA Compliant

Yes

Certifications

CE, FCC, IC

Software

Application Requirements

UniFi Network Version 9.1.120 and later

Manufacturer Part No:

USW-Pro-XG-24-PoE

Brand:

Ubiquiti

Product Type:

UPC

Product Family:

Unifi

Shipping Weight:

1.5 kg

PB Part No:

SWHUBI2424

Product Model:

USW-Pro-XG-24-PoE

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
