Winmate M101M8 2G 16GB Adriod 7.0 10.1" Rugged Tablet WIFI , ARM Cortex A53 Octa-Core1.1280x1080 Panel with P-Cap Touch, LTE, With 2D Barcode scanner, HotswapBattery,Dual Camera Design: 8MP Main camera with LED flash/2MP Webcam, Water and
Out of stock
Winmate M101M8 2G 16GB Adriod 7.0 10.1" Rugged Tablet WIFI , ARM Cortex A53 Octa-Core1.1280x1080 Panel with P-Cap Touch, LTE, With 2D Barcode scanner, HotswapBattery,Dual Camera Design: 8MP Main camera with LED flash/2MP Webcam, Water and
- Brand: Winmate
- MPN: M101M8-4EBMH
- Part #: TABWMAM101M8H
- UPC:
- Brand: Winmate
- MPN: M101M8-4EBMH
- Part #: TABWMAM101M8H
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial PCs & IoT





Winmate M101M8 2G 16GB Adriod 7.0 10.1" Rugged Tablet WIFI , ARM Cortex A53 Octa-Core1.1280x1080 Panel with P-Cap Touch, LTE, With 2D Barcode scanner, HotswapBattery,Dual Camera Design: 8MP Main camera with LED flash/2MP Webcam, Water and
- Brand: Winmate
- MPN: M101M8-4EBMH
- Part #: TABWMAM101M8H

Product URL: https://www.pbtech.com/pacific/product/TABWMAM101M8H/Winmate-M101M8-2G-16GB-Adriod-70-101-Rugged-Tablet
Features
10" Rugged Tablet
Key Features
- 10.1" 1280 x 800 WUXGA Panel with P-Cap Touch
- ARM Cortex A53 Octa-Core 1.3 GHz
- Android 7.0
- IP65 water and dust proof
- 8MP Main camera with LED flash in rear / 2MP Webcam in front
- LTE
- 2D Barcode Scaner
- HotswapBattery
- Default NFC Reader
Datasheet
http://download.winmate.com.tw/$Productfile/TabletPC/13_0255/M101M8-4E.pdf
User Guide
Specifications
Display Specifications
Size
10.1"
Brightness
400 (typ.)
Resolution
1280 x 800
Contrast Ratio
1000:1
Touch
Multi-touch projected capacitive
(supports Rain, Glove Mode)
Panel Viewability
Optical bonding for sunlight viewability
System Specification
Processor
ARM Cortex A53 Octa-Core 1.3 GHz
Memory
2GB LPDDR3
Storage
16GB eMMC, additional storage available with optional Storage Card SDHC (up to 32 GB)
Wireless Communication
WLAN
802.11 a/b/g/n
Bluetooth
Bluetooth 4.1
WWAN
LTE
GPS
Bulit-in
Barcode scaner
2D barcode scaner
I/O Connectors
Right I/O Connectors
1 x Micro USB 2.0 OTG
1 x Audio Combo connector (Mic in or Line Out)
1 x Power Jack
1 x Micro SD Card Slot
Downside I/O Connectors
1 x 19-Pin Docking Connector
Audio
1 x built-in Mic, 2 x 1 watt speaker
In front Control
Control Button
x power, 1 x home, 1 x back, 1 x menu, 2 x volume key
LED indicator
Status indicator
Mechanical and Environment
Dimensions (W x L x H)
271.8 x 197.2 x 19 mm (10.7 x 7.76 x 0.75 inches)
Net Weight (kg)
1 kg
Operating Temperature
-10°C to 50°C (Battery mode), -20°C to 60°C (4°F to 158°F) (AC mode)
Storage Temperature
-20°C to 60°C (4°F to 158°F)
IP Proof
IP65 certified, dustproof and waterproof
Operating Humidity
30% to 90% (non-condensing)
Certifications
CE, FCC
Shock
MIL-STD-810G Method 516.6 Procedure I
Vibration
MIL-STD-810G Method 514.6 Procedure I
Drop
MIL-STD-810G Method 516.6, 4 ft to concrete*
Power Management
Power Input
12~19V DC
Battery
7.4V, typ. 5140 mAh Li-Polymer Battery (2S1P)
Adapter
100-240V/ 12V DC 3A
Battery Operating Time Std. Battery:
Std. Battery: 10 hours **
Product Specification
OS
Android 7.0
NFC
Default NFC Reader
Barcode Scaner
2D
Battery
Hotswap Battery
NFC
NFC Reader
