ASUS IoT Rugged AI GPU system PE5101D Core i7 14700T Barebone 2.5 Hot-Swappable SSD/HDD Tray, RD 0/1 and up to 200W Graphics Card

PB Tech price
PB Tech price
NZD $ 2,957 .82
$ 2,957 .82

Out of stock

ASUS IoT Rugged AI GPU system PE5101D Core i7 14700T Barebone 2.5 Hot-Swappable SSD/HDD Tray, RD 0/1 and up to 200W Graphics Card

AI
  • Brand: ASUS IoT
  • MPN: PE5101D i7
  • Part #: WKSASU009
  • UPC:
PB Tech price
NZD $ 2,957 .82 $ 2,957 .82


Delivery: Out of stock
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info

Features

Rugged High Performance Edge Computer Supports Intel® 14th/ 13th/ 12th Gen Core™ i CPU, 2.5" Hot-Swappable SSD/HDD Tray, RAID 0/1 and up to 200W Graphics Card

- Supports Intel® 14th/ 13th/ 12th Gen Core™ i CPU with R680E chipset

- Supports dual 2.5" hot-swappable SSD/HDD tray & RAID 0/1

- Rich I/O with 3 x 2.5 GbE, 10 x USB, 6 x COM

- PCIe x16 & PCIe x4 expansion slots support up to 200-watt Graphics card

- 8 to 48V wide-range DC-in w/ built-in ignition power control

- Wide operating temperature range: -25° C to 60° C

Specifications

Processors

CPU

Intel® Core™ i7-14700T

TDP

35W

# of Cores

20

Base Freq.

1.3GHz

System

Chipset

Intel® R680E

Memory

2 x SO-DIMM (supports DDR5 ECC/non-ECC, up to 4800 MHz, max. 64GB)

I/O Interfaces

Display

1 x HDMI, supports up to 4096 x 2160 @ 30 Hz
2 x DP++, supports up to 4096 x 2160 @ 60 Hz

Ethernet

3 x 2.5 GbE, RJ45 (Intel® i226-IT)

AMT

Supports Intel® vPro/ AMT

USB

6 x USB 3.2 Gen 2 (10Gbps)
2 x USB 3.2 Gen 1 (5Gbps)
2 x USB 2.0

COM

2 x RS-232/422/485
4 x RS-232
1 x Mic-in

Audio

1 x Line-out

DIO

8-bit isolated DIO(4-in/4-out, terminal block, optional)

Storage

2.5" SATA

2 x 2.5" (supports hot-swappable SSD/HDD tray, RAID 0/1)

M.2 M Key

1 x M.2 2280 M-key (PCIe Gen4x4)

Expansion Slot

M.2 E-Key

1 x M.2 2230 E-key (PCIex1/USB2.0)

M.2 B-Key

1 x M.2 3042/3052 B-key with dual nano-SIM slot(PCIex1/USB 3.2 Gen1/USB2.0)

Mini PCIe

1 x Mini PCIe socket (PCIex1/USB 2.0)

PCIe Slot

1 x PCIe Gen4 x4 slot
1 x PCIe Gen4 x16 slot, the max in size 229 x 123.24 x 49.6 mm1 PCIe Slot

Power

Power input

8 to 48 V DC-in, 3-pin terminal block (V+, GND, IGN)

Remote switch

2-pin terminal block (Remote, GND)

Mechanical

Mounting

Wall-mount

Dimensions

242 x 241.4 x 137mm

Weight

5.81 kg

Environment

Operating Temp.

-25° C to 60° C 2,3

Storage Temp.

-40° C to 85° C

Relative Humidity

10 to 95% (non-condensing)

EMC

CE, FCC, BSMI

Safety

CE-LVD, CB, BSMI, CCC

Vibration

Operating: MIL-STD 810H Method 514.8, Category 4 & 3Grms, 5-500 Hz, 3 Axes

Shock

Operating: MIL-STD 810H Method 516.8, Procedure I, Table 516.6-ll; 20 G 11ms

Green

GA (RoHS)

Security

TPM

Supports dTPM v2.0

Others

Watch dog timer

Supported

OS

Windows® 11 IoT Enterprise (64-bit)
Windows® 10 IoT Enterprise (64-bit)
Linux by Project support

Manufacturer Part No:
PE5101D i7
Brand:
Product Type:
Core i7 14700T
UPC
-
Product Family:
Rugged AI GPU system
Shipping Weight:
1 kg
PB Part No:
WKSASU009
Product Model:
PE5101D
Warranty: 12 months *
