GigaIPC QBiX-JMB-ADLA67EH-A1 Industrial system with Intel Q470E Chipset, Intel Celeron Processor G6900E, discrete GFX card and 850W power supply

PB Tech price
PB Tech price
NZD $ 1,994 .66
$ 1,994 .66
$1,994.66  +GST
$1,994.66

GigaIPC QBiX-JMB-ADLA67EH-A1 Industrial system with Intel Q470E Chipset, Intel Celeron Processor G6900E, discrete GFX card and 850W power supply

  • Brand: GigaIPC
  • MPN: 6BQJQ67EAMR-SI-3P58
  • Part #: WKSGICQ20058
  • UPC:
PB Tech price
NZD $ 1,994 .66 $ 1,994 .66


Delivery: Order now and it ships on 14 Oct
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$1,994.66  +GST
$1,994.66

Features

Industrial system with Intel® Q670E Chipset, support for Intel® 14th/13th/12th Gen Processor / Display Port/ DVI-D port/ VGA port/ 2 x USB 3.2 Gen 1/ 2 x USB 3.2 Gen 2x1/ 6 x USB 2.0/ 4 x COM Ports/ 1 x 2.5GbE LAN Port/ 3 x GbE LAN Ports /M.2 slots

- System Size : 224W x 256.1D x 77.7H (mm)
- Support Intel® 14th/13th/12th Gen. Processor
- Dual Channel DDR4, 2 x SO-DIMMs
- DVI-D, VGA & DP ports for multiple display
- 1 x 2.5GbE LAN Port

Specifications

Dimension

224W x 256.1D x 77.7H(mm)

CPU

Support for 14th/13th/12th Generation
Intel® Core™ i9/i7/i5/i3, Pentium® and Celeron® processors in the LGA1700 package
TDP under 65W

Chipset

Intel® Q670E Express Chipset

Memory

2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual channel DDR4 3200 MHz memory modules

Ethernet

1 x 2.5GbE LAN Port (Intel® I226V)
1 x GbE LAN Port (Intel® I219LM, Vpro support)
2 x GbE LAN Ports (Intel® I211AT)

Graphics Support

Integrated Graphics Processor - depends on CPU:
1 x DP port, supporting a maximum resolution of 4096x2160 @60Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1080 @60Hz
1 x VGA port, supporting a maximum resolution of 1920x1080 @60Hz
(3 independent display outputs)

Audio

Realtek® ALC897

Storage

4 x 2.5" HDD/SSD (SATA 6Gb/s) -- support RAID 0/1/5/10

Expansion-Slots

1 x 2280 M.2 M-Key (PCIe Gen4x4)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot

Front I/O

1 x Power Switch/Power/HDD LED
3 x Audio Jacks (Line in, Line out, Mic in)
1 x Display port
1 x DVI-D
1 x VGA
2 x COM Ports (RS-232/422/485 & RI/5V/12V)
2 x COM Ports (RS-232)
4 x RJ45 LAN Ports
2 x USB 3.2 Gen 2x1
2 x USB 3.2 Gen 1
6 x USB 2.0
1 x 4-pin Terminal Block
2 x External Antenna Holes (Optional)

Power

+12V~48VDC (Full Range)

Operation Temperature

Operating temperature: -20°C to 50°C (CPU 65W TDP)
Operating temperature: -20°C to 60°C (CPU 35W TDP)
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-condensing)
Use wide temperature range memory and storage

Vibration During Operation

Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD/M.2 2280
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis

Shock During Operation

Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD

Packing Content

Carton size: 300 x 351 x 166 (mm)
Packing Capacity: 1
Weight: Approx. 5kg

Including:

Screw M3x4L x 20 (P/N: 25984G-1C014-S00)
Terminal Blocks Male Plug x 1 (P/N: 25IO0-2ESDV0-D2R)

Order Information

6BQJQ67EAMR-SI (Box packing)

Manufacturer Part No:
6BQJQ67EAMR-SI-3P58
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
WKSGICQ20058
Product Model:
QBiX-JMB-ADLA67EH-A1
Warranty: 12 months *
