Cambium Networks TX2012R-P Cambium cnMatrix TX 2012R-P, Intelligent Ethernet PoE Switch,CambiumSync,8 x 1gbps, and 4 SFP+, Removeable Power Supply (not included)

PB Tech price
PB Tech price
NZD $ 2,660 .87
$ 2,660 .87
$2,660.87  +GST
$2,660.87

Cambium Networks TX2012R-P Cambium cnMatrix TX 2012R-P, Intelligent Ethernet PoE Switch,CambiumSync,8 x 1gbps, and 4 SFP+, Removeable Power Supply (not included)

PB Tech price
NZD $ 2,660 .87 $ 2,660 .87
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 10 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$2,660.87  +GST
$2,660.87
Add To Compare
Stock Alerts
Click or hover over image to enlarge

10 Gigabit

Yes

10 Gigabit Ports

4 Ports

Form Factor

Not Specified

Management Level

Not Specified

Number of Ports

12 Ports

PoE

Yes

PoE Ports

8 Ports

PoE Budget

Not Specified

View full specs
Returns & Warranty Bulk Quote Print Page

Features

Cambium cnMatrix TX2012R-P 12-Port Gigabit PoE WISP Tower Switch

Cambium cnMatrix TX2012R-P is an Intelligent Ethernet PoE Switch with Cambium Sync, 8x 1gbps Ethernet Ports which support multiple PoE modes, and 4x SFP+ Ports. Power supply sold separately, supports Common Removeable Power Supplies (CRPS).

Cambium cnMatrix Tower Switches provide Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.

Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.

Cambium Sync

- Redundant Input Sync sources
- Internal GPS module (with external antenna)
- cnPulse port
- Full per-port control with stats available

Comprehensive/Intelligent PoE solution

- 802.3af/at/bt, up to 90W
- 24V Passive PoE, up to 15W
- 54V Passive PoE, up to 90W

- Comprehensive/Intelligent PoE solution, 802.3af/at/bt - up to 90W, 24V Passive PoE - up to 15W, 54V Passive PoE - up to 90W
- Supports CRPS AC/DC Removable power supplies (sold separately)
- Non-Blocking, Fully Managed, Enterprise Grade, L2/L3 switch
- Cambium (GPS) Sync - Redundant dual sources
- Easy and simple, free cloud (or on premise) management with cnMaestro™ or XMS
- Zero-touch deployment of switches makes installation easy
- Policy Based Automation eliminates manual and time consuming configuration
- Enhanced Security with automated device profiling and segmentation
- Unified Wired-Wireless access solution

Specifications

Throughput

104 Gbps

Forwarding Rate in Mpps (64 Byte Packets)

120

10/100/1000 Mbps RJ45 Ports

8

10 Gbps Fiber Ports (SFP+)

4

Serial Console

Yes

USB

Yes

Internal Fans

2

Flash Storage

128 MB

DRAM

512 MB

Cambium Sync (via RJ45 ports)

8

External Antenna Port (GPS)

Yes

cnPulse Port

Yes

Removable Power Supply Ports (CRPS)

1

Power Supply

CRPS dependent

Max Switch Power Consumption (WITH TRAFFIC)

38.88W

MTBF (hours)

393648

Unit Weight

2.24 kg

Unit Dimensions (H x L x W)

4.4 x 25 x 26 cm

CPU Speed

800 MHz

LEDs per port

Link/Activity, PoE

PoE Power Budget

CRPS dependent (see Datasheet)

802.3af/at/bt PoE (54V)

Ports 1-8

24V Passive PoE - up to 15W

Ports 5-8

54V Passive PoE - up to 90W

Ports 1-4

54V Passive PoE - up to 30W

Ports 5-8

PoE Max Power Per Port

30W/90W

Rack Mount Kit

Not Included (optional accessory)

Wall Mountable

Not Included (optional Accessory)

Temperature Ranges

-10°C up to 65°C

Operating Humidity

55°C at 95% RH

Storage Temperature

-40°C to 70°C

Manufacturer Part No:
TX2012R-P
Brand:
Cambium Networks
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
NETCBN010177
Product Model:
-
Warranty: 12 months *
