StarTech.com PEX40GQSFPI Dual Port 40G QSFP+ Network Card - Intel XL710 Open QSFP+ Converged Adapter - PCIe 40 Gigabit Ethernet Server NIC - 40GbE Fiber Optic LAN Card - Dell PowerEdge HPE ProLiant
- Brand: StarTech.com
- MPN: PEX40GQSFPI
- Part #: ADPSTT4520317
- UPC:065030872706

Product URL: https://www.pbtech.com/product/ADPSTT4520317/StarTechcom-PEX40GQSFPI-Dual-Port-40G-QSFP-Network
Features
Get fast, high-bandwidth connectivity with this QSFP+ server network card. The converged network adapter adds an open QSFP+ slot to your server or workstation. The 40Gb NIC features an Intel controller and provides reliable performance. It's ideal for high-demand database servers, virtualized servers and agile data centers that require infrastructure updates with no downtime.
Increase Your Network Speed
This QSFP+ server NIC lets you take advantage of the speed and stability of a 40 Gigabit Ethernet network, with data transfers of up to 40Gbps.
Add Scalable Network Connections
With an open QSFP+ slot, the network interface card supports QSFP+ transceiver modules and is compatible with multimode and single-mode fiber, providing a scalable networking solution.
Enhance Your Network Capabilities
The 40Gb NIC uses an Intel XL710 chipset, providing reliable connectivity and convergent network features. It offers many advanced features including Intel Virtualization Technology for Connectivity.
Applications
- Add ultra-fast 40Gbps network connectivity to database, file or application servers and high-performance workstations
- Utilize full 40Gpbs network speeds over longer distances than copper cabling
- Ideal for agile and high-demand data centers that require data security, no downtime, and infrastructure updates
Specifications
Hardware
Bus Type
PCI Express
Card Type
Standard Profile (LP bracket incl.)
Chipset ID
Intel XL710-BM1
Industry Standards
IEEE 802.3ba 40GBASE-SR4
IEEE 802.3ba 40GBASE-LR4
PCI Express Rev 3.0, using PCIe x8 (or higher) slot
Ports
1
Performance
Auto MDIX
Yes
Compatible Networks
40 Gbps
Full Duplex Support
Yes
Jumbo Frame Support
9K max.
Maximum Data Transfer Rate
40Gbps
Supported Protocols
IEEE 802.3ad (Link Aggregation)
IEEE 802.3x (2005 Flow Control Support)
IEEE 802.1Q (VLAN tagging)
Connector
Connector Type(s)
1 - PCI Express x8 Male
Internal Ports
1 - QSFP+ Female
SOFTWARE
OS Compatibility
Windows® 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
(Windows Drivers are supported in 64-bit only)
Linux 2.6.24 to 4.11.x (64-bit Only)< LTS Versions only
Indicators
LED Indicators
1 - Link LED/Activity LED
Enviromental
Humidity
5~95% RH
Operating Temperature
0°C to 57°C (32°F to 134.6°F)
Storage Temperature
-20°C to 85°C (-4°F to 185°F)
Physical characteristics
Color
Black
Product Height
0.8 in [2 cm]
Product Length
7.1 in [18.1 cm]
Product Width
4.8 in [12.1 cm]
Weight of Product
4 oz [112 g]
