Dynamix 15M USB 3.2 Full Featured Type C to C Hybrid Active Optical Cable

PB Tech price

AUD $ 486 .68

$ 486 .68

Dynamix 15M USB 3.2 Full Featured Type C to C Hybrid Active Optical Cable

Brand: Dynamix
MPN: C-U32-LLF-CC-15
Part #: CABDNX3065
UPC: 9420065713843

PB Tech price

AUD $ 486 .68

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 03 Jul

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Dynamix
MPN: C-U32-LLF-CC-15
Part #: CABDNX3065
UPC: 9420065713843

Be the first to review this product

Cable Length

Colour

Black

Connector 1

USB-C (Male)

Connector 2

USB-C (Male)

Braided

HDMI Version

View full specs

Returns & Warranty Bulk Quote Print Page

Features

The DYNAMIX C-U32-LLF-CC is a full-featured hybrid USB Type-C Active Optical Cable (AOC) designed to deliver high-speed data, DisplayPort video, & Power Delivery through a single USB-C connection. By utilizing optical fiber for high-speed signal transmission & copper conductors for power delivery, it overcomes the bandwidth & distance limitations of traditional copper cables while maintaining excellent signal integrity.

Supporting USB 3.2 Gen2 (10gbps) & DisplayPort 1.4 Alt Mode, the cable enables simultaneous video output, USB data transmission, & up to 60W PD charging. It operates in either 2-lane DP1.4 + USB 3.2 Gen2 mode or 4-lane DP + USB 2.0 mode, making it ideal for professional AV systems, medical imaging, broadcasting, machine vision, & high-performance computing applications.

- Supports USB 3.2 Gen2 data up to 10gbps
- Supports DisplayPort 1.4 video (DP Alt Mode over USB-C)
- Supported modes: 2-lane DP1.4 + USB 3.2 Gen2 (10gbps), 4-lane DP + USB 2.0 (480mbps)
- Enables simultaneous video, data, & power transmission
- Power Delivery up to 60W (PD 3.0, 20V/3A)
- Backward compatible with USB 2.0 / 1.1
- Plug & Play
- Hybrid optical fiber + copper construction
- Thin, more flexible design
- Highly resistant to EMI & RFI
- Resolution: 8K 60Hz (7680 x 4320)

Specifications

Connector Type

USB-C Male/USB-C Male

Power Delivery

10m = 60W, 20V/3A 15m = 40W, 20V/2A

Functionality

Data + Video + Power

Video Support

DisplayPort 1.4

Resolution

8K@60Hz

Configuration Modes

4-lane DP + USB 2.0 OR 2-lane DP1.4 + USB 3.2 Gen2

USB Data Rate

Up to 10gbps (USB 3.2 Gen2)

DP Bandwidth

8.1gbps per lane (DP1.4)

Cable Length

15m

Power Delivery

PD 3.0, up to 60W

Power Supply

3.0~5.5V

Cable Outer Diameter

6.5mm

Cable Structure

5-core optical fiber + 12 copper wires

Jacket Material

TPE (Black)

Cable Filler

Kevlar

Cable Colour

Black

Minimum Bend Radius

20mm (dynamic) / 10mm (static)

Cable Pressure Resistance

200N (long term) / 400N (short term)

EMI / RFI Resistance

High immunity to electromagnetic interference

Operating Tempreture

-20°C ~ 80°C

Manufacturer Part No:

C-U32-LLF-CC-15

Brand:

Dynamix

Product Type:

UPC

9420065713843

Product Family:

Shipping Weight:

1 kg

PB Part No:

CABDNX3065

Product Model:

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
