FUSION APOLLO RA670 MARINE ENTERTAINMENT SYSTEM WITH DSP

PB Tech price
PB Tech price
AUD $ 698 .02
$ 698 .02
$698.02  +GST
$698.02

FUSION APOLLO RA670 MARINE ENTERTAINMENT SYSTEM WITH DSP

  • Brand: FUSION
  • MPN: 010-02138-00
  • Part #: CARFSN1003
  • UPC:
PB Tech price
AUD $ 698 .02 $ 698 .02


Delivery: Order now and it ships on 12 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$698.02  +GST
$698.02

Features

AWARD-WINNING INNOVATION REEMBODIED

The Apollo RA670 marine stereo inherits key audio innovations and revolutionary technology from the award-winning Apollo RA770, reimagined in a compact form factor.


DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS

Built on the True-Marine design philosophy from Fusion®, the Apollo RA670 stereo has an IPX6 and IPX7 rated water-resistant front panel and has been tested to a high level of protection against salt, fog, temperature, vibration and UV.

MODERN DESIGN AND AESTHETICS

Providing uniformity across the helm, the black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy, uniform and elegant installation.

STEREO GROUPING

Grouping allows you to link up multiple Apollo Series stereos connected to the same network and play the same audio source synchronised across all stereos.

VOLUME CONTROL

Scroll through available zones on your boat, and enjoy independent volume control, or select ALL volume to adjust a group of stereos at once.

POWER OPTIONS

Power options allow you to turn on any connected Apollo Series stereo in standby mode on the Fusion PartyBus-Network remotely from another Apollo Series stereo.

HOME ZONE

Home Zone is the physical zone onboard your boat in which the stereo is installed. After adjusting audio in another zone, the stereo defaults to control of the Home Zone after a period of inactivity.





Specifications

General

Physical dimensions Stereo dimensions (H x W x D)

68 x 157 x 123 mm

Weight

750 g

Water rating

IPX6 and IPX7 (front panel only, when properly installed)

Power input

10.8-16 VDC

Operating temperature range

0° to 50° C

Current (max.)

15 A

NMEA 2000 LEN

1 (50 mA)

Bluetooth wireless range

10 metres

ANT wireless range

3 metres

Wireless frequencies/protocols

Bluetooth 2.4 GHz @ +13.29 dBm nominal
ANT 2.4 GHz @ +6.92 dBm nominal

Compass-safe distance

200 mm

Stereo features

Display

2.7-inch optically bonded colour LCD

Built-in amplifier

Class-D (2 Ohm stereo-stable)

Peak power

280 W

Rated power output (2 Ohm)

43 W rms x 4 @ 14.4 V input < 10% THD

Rated power output (4 Ohm)

26 W rms x 4 @ 14.4 V input < 10% THD

Built-in Digital Signal Processing

Yes (with preconfigured DSP profiles)

PartyBus™-Network capabilities

Yes (wired)

Fusion-Link™ control

Yes (with MFD, smartphone and Garmin watch)

Multi-Zone™ technology

3 zones

Bluetooth wireless technology

Yes

ANT wireless technology

Yes

SiriusXM-ready

Yes (requires SiriusXM Connect vehicle tuner)

DAB+ ready

Yes (requires DAB100A antenna module)

Optical audio input

Yes

NRX remote compatibility

Yes

Software updates

Over-the-air software updates via the Fusion-Link app*, USB

Sources

AM / FM / Bluetooth / Apple AirPlay 2* / digital optical input / USB audio / iPhone / iPod / AUX x1 / UPnP* / MTP / SiriusXM-Ready (USA only, requires optional SiriusXM Connect vehicle tuner) / DAB+ ready (available in Europe and Australia only)

Connectivity

Auxiliary input

One RCA input (AUX)

Optical audio input

One digital optical input (SPDIF) port

Ethernet

One Ethernet port

NMEA 2000

One NMEA 2000 port

USB 2.0

One USB 2.0 port

SiriusXM satellite radio

One SiriusXM port (requires SiriusXM Connect vehicle tuner; does not support traffic and weather)

AM/FM radio

One Motorola antenna connector port

Speaker

4 x speaker connections (2 zone amplified)

RCA Pre-out (left, right and subwoofer)

3 zones (requires external amplification)

Line out

3 (1 x L + R per zone, requires external amplification)

Subwoofer out

1 x mono output (requires external amplification)

Manufacturer Part No:
010-02138-00
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
CARFSN1003
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
