FUSION APOLLO RA670 MARINE ENTERTAINMENT SYSTEM WITH DSP
- Brand: FUSION
- MPN: 010-02138-00
- Part #: CARFSN1003

Product URL: https://www.pbtech.com/product/CARFSN1003/FUSION-APOLLO-RA670-MARINE-ENTERTAINMENT-SYSTEM-WI
Features
AWARD-WINNING INNOVATION REEMBODIED
The Apollo RA670 marine stereo inherits key audio innovations and revolutionary technology from the award-winning Apollo RA770, reimagined in a compact form factor.
DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS
Built on the True-Marine design philosophy from Fusion®, the Apollo RA670 stereo has an IPX6 and IPX7 rated water-resistant front panel and has been tested to a high level of protection against salt, fog, temperature, vibration and UV.
MODERN DESIGN AND AESTHETICS
Providing uniformity across the helm, the black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy, uniform and elegant installation.
STEREO GROUPING
Grouping allows you to link up multiple Apollo Series stereos connected to the same network and play the same audio source synchronised across all stereos.
VOLUME CONTROL
Scroll through available zones on your boat, and enjoy independent volume control, or select ALL volume to adjust a group of stereos at once.
POWER OPTIONS
Power options allow you to turn on any connected Apollo Series stereo in standby mode on the Fusion PartyBus-Network remotely from another Apollo Series stereo.
HOME ZONE
Home Zone is the physical zone onboard your boat in which the stereo is installed. After adjusting audio in another zone, the stereo defaults to control of the Home Zone after a period of inactivity.
Specifications
General
Physical dimensions Stereo dimensions (H x W x D)
68 x 157 x 123 mm
Weight
750 g
Water rating
IPX6 and IPX7 (front panel only, when properly installed)
Power input
10.8-16 VDC
Operating temperature range
0° to 50° C
Current (max.)
15 A
NMEA 2000 LEN
1 (50 mA)
Bluetooth wireless range
10 metres
ANT wireless range
3 metres
Wireless frequencies/protocols
Bluetooth 2.4 GHz @ +13.29 dBm nominal
ANT 2.4 GHz @ +6.92 dBm nominal
Compass-safe distance
200 mm
Stereo features
Display
2.7-inch optically bonded colour LCD
Built-in amplifier
Class-D (2 Ohm stereo-stable)
Peak power
280 W
Rated power output (2 Ohm)
43 W rms x 4 @ 14.4 V input < 10% THD
Rated power output (4 Ohm)
26 W rms x 4 @ 14.4 V input < 10% THD
Built-in Digital Signal Processing
Yes (with preconfigured DSP profiles)
PartyBus™-Network capabilities
Yes (wired)
Fusion-Link™ control
Yes (with MFD, smartphone and Garmin watch)
Multi-Zone™ technology
3 zones
Bluetooth wireless technology
Yes
ANT wireless technology
Yes
SiriusXM-ready
Yes (requires SiriusXM Connect vehicle tuner)
DAB+ ready
Yes (requires DAB100A antenna module)
Optical audio input
Yes
NRX remote compatibility
Yes
Software updates
Over-the-air software updates via the Fusion-Link app*, USB
Sources
AM / FM / Bluetooth / Apple AirPlay 2* / digital optical input / USB audio / iPhone / iPod / AUX x1 / UPnP* / MTP / SiriusXM-Ready (USA only, requires optional SiriusXM Connect vehicle tuner) / DAB+ ready (available in Europe and Australia only)
Connectivity
Auxiliary input
One RCA input (AUX)
Optical audio input
One digital optical input (SPDIF) port
Ethernet
One Ethernet port
NMEA 2000
One NMEA 2000 port
USB 2.0
One USB 2.0 port
SiriusXM satellite radio
One SiriusXM port (requires SiriusXM Connect vehicle tuner; does not support traffic and weather)
AM/FM radio
One Motorola antenna connector port
Speaker
4 x speaker connections (2 zone amplified)
RCA Pre-out (left, right and subwoofer)
3 zones (requires external amplification)
Line out
3 (1 x L + R per zone, requires external amplification)
Subwoofer out
1 x mono output (requires external amplification)
