Dynamix FP-C6A-180WH Cat6A 180 Unshielded Keystone Jack, Dual IDC. Colour White

Normally $5.77

You save 11%

AUD $ 5 .13

$ 5 .13

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

Dynamix FP-C6A-180WH Cat6A 180 Unshielded Keystone Jack, Dual IDC. Colour White

Brand: Dynamix
MPN: FP-C6A-180WH
Part #: CHSDNX1173
UPC:

CLEARANCE

Normally $5.77

You save 11%

PB Tech price

AUD $ 5 .13

In stock

Delivery: Order now and it ships today

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Dynamix
MPN: FP-C6A-180WH
Part #: CHSDNX1173
UPC:

Be the first to review this product

Cable Length

Returns & Warranty Bulk Quote Print Page

Features

DYNAMIX Cat6A 180 Unshielded Keystone Jack, Dual IDC. Colour White

The DYNAMIX Cat6A component compliant RJ45 180° unshielded keystone jacks are designed to easily snap in and out of the wall outlet, patch panel and surface mount box. The jacks are individually terminated using Insulation Displacement Connectors (IDC) with a rapid punch down tool available for quick installation. The unique design provides an efficient and effective method of reducing alien crosstalk from neighbouring connectors for superior performance.

FEATURES:

DYNAMIX keystone jacks meet and exceed performance levels for Cat6A
Rapid Termination tool available (Purchased separately)
Comes with T568A/T568B colour labelling
Press-Fit Technology makes the product more reliable
Hardware transmission performance edition 2.2 of ISO/IEC 11801, CENELEC 50173-1, and ANSI/TIA-568-C.2 for Return loss, Insertion loss, NEXT loss, FEXT loss, TCL, TCTL, PSANEXT loss, and PSAFEXT loss up to 500MHz
More stable transmission performance is guaranteed since there is no other medium that takes effect in between PCB and contacts
Limited Lifetime warranty

Specifications

Material

Housing

ABS UL94V-0 flame retardancy

Spring Wire

Phosphor bronze 0.35t, plated with 50u" gold at contact area over 60u" nickel undercoat

PCB

FR4

IDC Terminals

Phosphor bronze 0.5t, plated with 100u" nickel

IDC Block

High-impact Polycarbonate UL94V-2 flame retardancy

Solid Wire Range

Conductor Diameter

24AWG - 22AWG

Insulation Diameter

0.8mm - 1.1mm

Cable Diameter

5mm - 9mm

Plug Insertion Life (Mating)

750 cycles with FCC compliant plug

Plug and Jack Contact Force

min. 100g using FCC approved plug

Plug Retention Force

min. 30lbs

Storage Temperature

-40° ~ 68°

Operating Temperature

-10° ~ 60°

Operating Humidity

10% ~ -90%RH

Current Rating

1.5A

Insulation Resistance

min. 500mO

Contact Resistance

max. 20mO

Transmission Performance

10GBase-T

FCC

Part 68

TIA/EIA

568-C.2

1863
ETL Certified
Supports POE+
US PATENT

Manufacturer Part No:

FP-C6A-180WH

Brand:

Dynamix

Product Type:

UPC

Product Family:

Shipping Weight:

0.1 kg

PB Part No:

CHSDNX1173

Product Model:

Warranty: 60 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
