Transcend Embedded M.2 2242 SSD, 512GB, SATA3 B+M Key, 3D TLC BiCS5, PE: 3K, 30u

Normally $121.05
Normally $121.05
You save $12
You save $12
AUD $ 108 .86
$ 108 .86
$108.86  +GST
$108.86

Transcend Embedded M.2 2242 SSD, 512GB, SATA3 B+M Key, 3D TLC BiCS5, PE: 3K, 30u

Normally $121.05
Normally $121.05
You save $12
You save $12
PB Tech price
AUD $ 108 .86 $ 108 .86
In stock at Supplier
Delivery: Order now and it ships on 23 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$108.86  +GST
$108.86
Add To Compare
Stock Alerts
Click or hover over image to enlarge
Returns & Warranty Bulk Quote Print Page

Features

Transcend's M.2 SSD MTS570T features the SATA III 6Gb/s interface and the state-of-the-art 3D NAND technology, which allows 112 layers of 3D NAND flash chips to be vertically stacked. Compared to 3D NAND at 96 layers, this density breakthrough greatly improves storage efficiency, and its built-in DRAM cache allows faster access. Applied with 30µ" gold finger PCB and Corner Bond technology, the MTS570T is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles and an extended operating temperature ranging from -20?~75?.

Transcend also offers the MTS570T-I with wide temperature (-40? ~ 85?) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.

Firmware Features

- Dynamic thermal throttling
- Built-in LDPC ECC (Error Correction Code) functionality
- Advanced Global Wear-Leveling and Block management for reliability
- Advanced Garbage Collection
- Static Data Refresh
- Early Move
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- TRIM command for better performance
- NCQ command for better performance
- Full drive encryption with Advanced Encryption Standard (AES) (optional)
- Power-saving DevSleep (Device Sleep) mode (optional)

Hardware Features

- Compliant with RoHS 2.0 standards
- Space-saving M.2 form factor (42mm) - ideal for mobile computing devices
- DDR3 DRAM Cache embedded
- Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
- Key components fortified by default with Corner Bond technology
- 30µ" PCB gold finger
- Anti-sulfur technology implemented to prevent sulfurization in the environment
- Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
- Extended Temp. (-20°C ~ 75°C) and Wide Temp. (-40°C ~ 85°C) options available
- Supports Transcend Scope Pro software

Specifications

Appearance

Dimensions

42.0 mm x 22.0 mm x 3.58 mm (1.65" x 0.87" x 0.14")

Weight

5 g (0.18 oz)

M.2 Type

2242-D2-B-M (Double-sided)

Form Factor

M.2 2242

Interface

Bus Interface

SATA III 6Gb/s

Storage

Capacity

512 GB

Flash Type

112-layer 3D NAND flash

Operating Environment

Operating Voltage

3.3V±5%

Operating Temperature

Extended Temp.-20°C (-4°F) ~ 75°C (167°F)
Wide Temp.-40°C (-40°F) ~ 85°C (185°F)

Storage Temperature

-55°C (-67°F) ~ 85°C (185°F)

Humidity

5% ~ 95%

Shock

15 G, 11 ms, 3 axis

Vibration (Operating)

20 G (peak-to-peak), 7 Hz ~ 2,000 Hz (frequency)

Power

Power Consumption (Operation)

4.5 watt(s)

Power Consumption (IDLE)

1.1 watt(s)

Performance

Sequential Read/Write (CrystalDiskMark)

Read: Up to 560 MB/s
Write: Up to 520 MB/s

4K Random Read/Write (IOmeter)

Read: Up to 90,000 IOPS
Write: Up to 85,000 IOPS

Mean Time Between Failures (MTBF)

3,000,000 hour(s)

Terabytes Written (TBW)

Up to 2420 TBW

Drive Writes Per Day (DWPD)

2.16 (3 yrs)

Note

Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Terabytes Written (TBW) expresses the endurance under the highest capacity.

Warranty

Certificate

CE/UKCA/FCC/BSMI

Warranty

Three-year Limited Warranty

Warranty Policy

Please click here for more information about the Transcend Warranty Policy.
Warranty does not apply when Scope Pro software wear-out indicator displays 0% within the warranty coverage.
Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios. For special applications and environments, it is strongly suggested that you contact Transcend beforehand for clarification.
Scope Pro software is required by request. Please contact us for more information.

Manufacturer Part No:
TS512GMTS570T
Brand:
Transcend Embedded
Product Type:
M.2 2242 SSD,
UPC
760557855811
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
HDDTRSI12059
Product Model:
-
Warranty: 12 months *
