Advantech ICR-1601G2201-T Industrial Entry-Level 4G Router with GPS, EMEA Cat.4, 2 ETH, ACC(LTE/GPS Only)
Advantech ICR-1601G2201-T Industrial Entry-Level 4G Router with GPS, EMEA Cat.4, 2 ETH, ACC(LTE/GPS Only)
- Brand: Advantech
- MPN: ICR-1601G2201-T
- Part #: IPCAVH070003
- UPC:
- Brand: Advantech
- MPN: ICR-1601G2201-T
- Part #: IPCAVH070003
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Network Appliances





Advantech ICR-1601G2201-T Industrial Entry-Level 4G Router with GPS, EMEA Cat.4, 2 ETH, ACC(LTE/GPS Only)
- Brand: Advantech
- MPN: ICR-1601G2201-T
- Part #: IPCAVH070003

Product URL: https://www.pbtech.com/product/IPCAVH070003/Advantech-ICR-1601G2201-T-Industrial-Entry-Level-4
Features
- LTE B1, B3, B7, B8, B20
- DIN and Wall mount options
- 2x ETH
- GNSS receiver
- Operating temp. -30 °C to +70 °C, Power input : 5-18VDC (DC Jack), accessory with EU type power adapter
- Certifications: CE
- Diagnostics, VPN support, Firewall, WAN failover
Specifications
PORTS, LED, ANTENNAS
2× Ethernet
RJ45, 10/100 Mbps
2× SIM
SIMs Micro (3FF)
1× MicroSD
MicroSD card slot (System log)
LED indicators
WAN, System
2× ANT
SMA connectors
GNSS (GPS, GLONASS) - *optional
SMA connector
WiFi antenna - *optional
R-SMA connector
POWER, CONSUMPTION, ENVIRONMENTAL
Power Supply
5-18VDC (DC Jack)
Consumption
7 W
Temperature Range - Operating / Storage
-30 to +70 °C / -40 to +85 °C
Humidity - Operating / Storage (non-condensing)
10 to 95 % / 10 to 95 %
MECHANICAL
Metal case
Wall mount & and DIN mount options
Enclosure Dimensions
93×90×27mm (100mm including antenna connectors)
Weight
252 g
WI-FI
Antenna Connector
1× R-SMA - 50 Ohms
Supported WiFi band
2.4 GHz
Standards
802.11n, 802.11g, 802.11b
2.4 GHz supported channels
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
Functions
Multi-SSID, WMM, WDS
Security
WEP, WPA,WPA2, WPA-PSK, WPA2-PSK, 802.1x
Type of device
Access Point
