Advantech ADAM-4069-B 8Power Relay Modbus RS-485 Remote I/O
- Brand: Advantech
- MPN: ADAM-4069-B
- Part #: IPCAVH220068

Product URL: https://www.pbtech.com/product/IPCAVH220068/Advantech-ADAM-4069-B-8Power-Relay-Modbus-RS-485-R
Features
ADAM-4069
8Power Relay Modbus RS-485 Remote I/O
- 8ch power relay
- Protocols:Modbus RTU,ASCII
- Watchdog timer to recover the system
Specifications
General
Certification
FCC, CE
Connectors
2 x plug-in terminal blocks (#14 ~ 28 AWG)
Power Consumption
1.3 W @ 24 V DC typ.
2.3 W @ 24 V DC max.
Watchdog Timer
System (1.6 second) & Communication
Supported Protocols
ASCII command and Modbus/RTU
Relay Output
Breakdown Voltage
1,000 VAC (50/60 Hz)
Channels
4 x Form A
4 x Form C
Contact Rating (Resistive)
5 A @ 250 VAC
5 A @ 30 VDC
Initial Insulation Resistance
1 GO min. at 500 VDC
Relay off Time (Typical)
5.6 ms
Relay on Time (Typical)
5 ms
Maximum Operating Speed
6 operations/min (at related load)
General
Power Input
Unregulated 10 ~ 30 VDC
Environment
Operating Humidity
5 ~ 95% RH
Operating Temperature
-10 ~ 70°C (14 ~ 158°F)
Storage Temperature
-25 ~ 85°C (-13 ~ 185°F)
