Advantech PCIE-1841-A 1MS/s/ch, 18-bit, 16-ch, Simultaneous AI card

Normally $6,179.26

You save $189

AUD $ 5,989 .40

$ 5,989 .40

Advantech PCIE-1841-A 1MS/s/ch, 18-bit, 16-ch, Simultaneous AI card

Brand: Advantech
MPN: PCIE-1841-A
Part #: IPCAVH221107
UPC:

Normally $6,179.26

You save $189

PB Tech price

AUD $ 5,989 .40

In stock at Supplier

Delivery: Order now and it ships on 30 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: PCIE-1841-A
Part #: IPCAVH221107
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

- 16/8-ch simultaneous sampling up to 1 MS/s
- 18-bit resolution
- Software selectable low-pass filter
- Wide input range up to 40 Vpp (±20 V range)
- Support both voltage and current measurement
- Multiple selectable trigger modes

For more information: https://advdownload.advantech.com/productfile/PIS/PCIE-1841/file/PCIE-1841_1841L_DS(101323)20231013175801.pdf

Specifications

MPN

PCIE-1841-A
16-ch, 18-bit, 1MS/s/ch, simultaneous sampling card

Analog Input

Channels

16 differential

Analog-to-digital converter (ADC) resolution

18 bits

Input range

±20 V, ±12.5 V, ±10 V, ±5 V, or
±20 mA, software configurable per channel

Maximum input voltage

±20 V

Input common-mode voltage range

±20 V range ±10 V
±12.5 V range ±6.25 V
±10 V range ±5 V
±5 V range ±2.5 V

Over-voltage protection

±30 V

Input coupling

Input impedance

Voltage input 1 MO
Current input 500 O

Analog low-pass filter

-3 dB bandwidth

22.5 kHz or 250 kHz, software configurable per channel

Acquisition type

Instant or buffered, software configurable

Buffered Acquisition

Enabled channel combination

Each channel can be enabled/disabled independently by software

Sample rate

1 MHz max., for all channels, simultaneous sampling, software configurable

On-board FIFO Size

8192 Samples

Absolute accuracy

Voltage input

Operating temperature within ±5°C of last Auto-calibration temperature
±0.01% of full-scale range max.
Over full operating temperature range
±0.05% of full-scale range max.

Current input

Operating temperature within ±5°C of last Auto-calibration temperature
±0.1% of full-scale range max.
Over full operating temperature range
±0.5% of full-scale range max.

Trigger

Number of triggers

Trigger action

Start, delay to start, stop, or delay to stop

Trigger delay range

0 ~ 16,777,215 samples

Sample number

0 ~ 16,777,215 samples

Mechanical

Connector Type

DB-62 connector

Dimension

175 x 100mm (6.9" x 3.93")

Weight

0.12 kg

Environment

Operating temperature

0 °C to 60 °C (-4 °F to 140 °F)

Storage temperature

-40 °C to 70 °C (-40 °F to 158 °F)

Operating humidity

10% to 90% RH, non-condensing

Storage humidity

5% to 95% RH, non-condensing

Certification

EMC

CE, FCC

Manufacturer Part No:

PCIE-1841-A

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221107

Product Model:

PCIE-1841-A

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
