Features
Advantech UNO-238-C7N1AE i7-1265UE,4xUSB 3.2 DP+HDMI,2xCOM,GPIO/CANBus
- 12th Gen Intel® Core™ i Processor up to 10 Cores
- Dual Channel DDR5-4800 up to 64GB
- M.2 E-Key, B-Key, M-Key (support NVMe) expansion for storage/wireless
- Equipped with CANBus for reliable communication
- DC-in terminal block for wiring flexibility
- Supports multiple displays for ThinManager solution
- Supports software APIs, WISE DeviceOn, WISE Edge365
Specifications
Environment
Ingress Protection
IP20
Operating Temperature
-20~60 °C (-4~140 °F)
Relative Humidity
5~95% RH (non-condensing)
Shock Protection
50 G, half sine
Storage Temperature
-40~85 °C (-40~185 °F)
Vibration Protection
2 Grms, random
Hardware
Certification
CB, UL, CE, FCC, CCC, BSMI
CPU
Intel® Core™ i7-1265UE 1.7GHz Alder Lake 10-Core
Graphics Engine
Intel® Iris Xe® Graphics
Hardware Security
TPM 2.0
Memory
2 x SO-DIMM Slot with DDR5 4800MHz
OS Support
Microsoft® Windows 10 LTSC, Microsoft® Windows 11, Linux
Power Input
12~24 VDC
Storage
1 x SATA M.2 SSD slot (2280 M-Key)
LED Indicators
PWR
Watchdog Timer
1~255 s
I/O
2 x CAN Bus, 4 x USB 3.2, 2 x Type C, 1 x GPIO
I/O Interface
Displays
1 x HDMI, 1 x DP
Expansion
1 x M.2 B key, 1 x M.2 E key
LAN Ports
1 x 10/100/1000 Mbps, 1 x 10/100/2500 Mbps
Power Connector
1 x 10-Pin Terminal Block
Serial Ports
2 x RS 232/422/485
Mechanical
Dimension (W x H x D)
150 x 107 x 60 mm
Enclosure
Aluminum housing
Weight (Net)
1.8 kg (3.96 lb)
Mounting
Stand, Din-rail
