Advantech Modular design Panel PC FPM-D15T-RE 15" (4:3) modular front display Resistive Touch design, compatible with TPC-Bxxx Series
- Brand: Advantech
- MPN: FPM-D15T-RE
- Part #: IPCAVH500035
Product URL: https://www.pbtech.com/product/IPCAVH500035/Advantech-Modular-design-Panel-PC-FPM-D15T-RE-15-4
Features
Advantech FPM-D15T-RE 15" (4:3) modular front display design compatible with TPC-Bxxx Series
- 350 cd/m² luminance with 1024 x 768 resolution
- High durability and performance with industrial-Grade LED LCD
- 5-Wire resistive touch technology
- IP66-rated front panel and panel mount support
- User-friendly system status LED indicators
High-Performance Touch Display
The Advantech FPM-D15T-RE is a 15-inch industrial-grade touch display designed to deliver high-resolution visuals with reliable performance in demanding environments. Its robust construction ensures clear, vivid images, making it ideal for industrial control panels, kiosks, and point-of-sale applications.
Durable Touch Technology
Equipped with resistive touch technology, the FPM-D15T-RE provides accurate and responsive touch input, even when operated with gloves or a stylus. This makes it highly suitable for industrial and commercial settings where precision and durability are essential.
Rugged Industrial Design
Engineered for tough environments, the FPM-D15T-RE features a fanless, sealed design that protects against dust and debris. Its durable housing and high-quality materials make it capable of withstanding continuous operation in industrial, manufacturing, and commercial applications.
Specifications
Environment
Ingress Protection
IP66
Operating Temperature
-20~60 °C (-4~140 °F)
Storage Temperature
-30~70 °C (-22~158 °F)
Hardware
Certification
CB, UL, CE, FCC Class A
LCD Display
Backlight Life (hrs)
70,000
Display Size
15"
Luminance (cd/m2)
300
Max. Resolution
1024 x 768
Viewing Angle (H/V°)
176/176
Mechanical
Dimension (W x H x D)
383.2 x 307.3 x 27.5 mm
Mounting
Panel, Wall, Stand, VESA
Weight (Net)
3.8 kg (8.38 lb)
Touchscreen
Touch Type
5-wire resistive
