Dracal USB-DXC120 Calibratable USB Carbon dioxide (CO2) gas sensor

PB Tech price

AUD $ 248 .74

$ 248 .74

Dracal USB-DXC120 Calibratable USB Carbon dioxide (CO2) gas sensor

Brand: Dracal
MPN: USB-DXC120
Part #: IPCDAL20013
UPC:

PB Tech price

AUD $ 248 .74

In stock at Supplier

Delivery: Order now and it ships on 01 Jul

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Dracal
MPN: USB-DXC120
Part #: IPCDAL20013
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

DXC120: USB CO2 sensor for monitoring indoor air quality.

The DXC120 is a compact and high-performance carbon dioxide (CO2) detector, ideal for monitoring CO2 levels in environments such as homes, workplaces, or any other spaces with moderate conditions. Like all instruments in the DXC series, it is based on advanced non-dispersive infrared (NDIR) technology, ensuring high precision and exceptional stability with its integrated automatic calibration mechanism that compensates for long-term drift. Manual calibration can also be easily performed with a single click via Dracal's software for added flexibility. The DXC120 offers a typical accuracy of ±(30 ppm + 3%) and repeatability of ±10 ppm, with temperature stability of 2.5 ppm/°C, ensuring consistent and reliable measurements even with temperature variations. With an operational lifespan of 15 years and individual factory calibration, this device is a durable and reliable investment for any application requiring rigorous CO2 monitoring.

Easy to use in your applications

- Virtual COM option (VCP)
- dracal-usb-get: command-line data integration tool
- dracal-sensgate-get: command-line tool for wireless access to sensors connected to a SensGate
- RVCP: REST API for wireless access to VCP instruments connected to a SensGate

Multiple integration and code examples, including Python, C, C++, Java, Node.js, C#, Grafana and LabVIEW.

Possible applications

- Greenhouse
- Office, home monitoring
- Vivarium
- OEM integration
- Warehouses
- Education

Free data monitoring and calibration software

Be instantly operational with DracalView: Dracal's free data visualization, logging and calibration software

- Works under Windows (Win7/8/10/11 64&32-bit), Mac OS X and Linux
- Simultaneous visualization and logging of an unlimited number of sensors
- Automatic synchronization with Dracal's Wi-Fi gateway
- Easy calibration mechanism open to the end-user

Like all Dracal measurement instruments, the DXC120 is compatible with free software tools, making it an essential component of a DAQ solution. For those who wish to integrate the DXC120 into their system, there are two options available: command line tools and VCP mode. If you prefer a graphical interface, DracalView is the appropriate choice.

Specifications

Carbon Dioxide

Carbon Dioxide Range

From 400 to 10,000 ppm

Accuracy

±(30 ppm + 3%MV)

Accuracy Drift Over Lifetime

± 50 ppm

Sensor IC

Sensirion SCD30

Sensor Lifetime

15 years

Technology

NDIR

Calibration

Integrated continuous self-calibration mechanism

Detection

Dual-channel detection

Miscellaneous

Operating Temperature Range

0°C to 50°C

Power Supply

Powered through USB

Communication

USB 2.0

Average Current

30 mA

Maximum Current During Measurement

85 mA

Enclosure

ABS Plastic, USB-key form factor

Weight

21 g

Overall Dimension

H 2.9″ (74 mm) x W 1.35″ (34 mm) x D 0.72″ (18 mm)

Manufacturer Part No:

USB-DXC120

Brand:

Dracal

Product Type:

UPC

Product Family:

Shipping Weight:

0.01 kg

PB Part No:

IPCDAL20013

Product Model:

USB-DXC120

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
