Giada DF612-i5 Core i5-1235U CPU, Barebone, Windows/Linux, 1xDP+2xHDMI, Fanless, 8K Display,

PB Tech price
PB Tech price
AUD $ 694 .63
$ 694 .63

Out of stock

Giada DF612-i5 Core i5-1235U CPU, Barebone, Windows/Linux, 1xDP+2xHDMI, Fanless, 8K Display,

  • Brand: Giada
  • MPN: DF612-i5
  • Part #: IPCGDA20012
  • UPC:
PB Tech price
AUD $ 694 .63 $ 694 .63


Delivery: Out of stock
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info

Features

High Computing Performance
Powered by Intel® 12th Gen. CPU
Giada DF612 adopts Intel 12th-Gen processors of i3-1215U, i5-1235U, i7-1255U which deliver 19 percent more performance than today's 11th-gen "Rocket Lake". DF612 has the Intel vPro and TPM 2.0 features to deliver increased productivity, remote manageability and data security.

Three Display Outputs
Supporting 8K Display
DF612 supports Intel® integrated Iris® Xe GPU (Core i5/i7). It can deliver up to 1 x 8K (7680 x 4320@60 Hz) display via DP1.4 port, or 2 x 4K displays (4096 x 2304@60Hz) via 2 x HDMI2.0 ports. It's an ideal choice for large-format displays and Kiosk in 24/7 use.

Intel® vPro Technology
Intel® Hardware Shield delivers integrated hardware-based PC protection, which includes below-the-OS security, application and data protection, and advanced threat detection.


Fanless Design
With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device running with noise-free and dustproof. It enables this Giada® device applicable in mission critical applications

                               I/O port introduction


Specifications

CPU

CPU

Intel® Core™ i5-1235U processor

Efficient Frequency

3.30 GHz/3.30 GHz/3.50 GHz

Performance Frequency

4.40 GHz/4.40 GHz/4.70 GHz

Chipset

SoC

Processing Units

6 Cores /10 Cores /10 Cores

Configurable TDP-up

15 W /15 W /15 w

Memory

Size

Up to 64 GB

Type

2 x SO-DIMM DDR4-3200 MHz

Storage Socket 1

1 x M-Key M.2 (2242/2280) for PCIe SSD

Display

GPU

Intel® UHD Graphics (Core™ Core i3)
Intel® IRIS® Xe Graphics (Core™ Core i5/i7)

Graphic Engine

DirectX 12.1, OpenGL 4.6, OpenCL 3.0, 8K 60fps 12b 4:2:0 HEVC/VP9/SCC

Display Interface

1 x DP (Max.7680 x 4320 @60 Hz)
2 x HDMI (Max.4096 x 2304 @60 Hz)

Network

Network Controller

1 x Intel i219-LM Gigabit Ethernet
1 x Realtek RTL8111H Gigabit Ethernet

Ethernet Interface

2 x RJ45

Wi-Fi/BT

1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E (CNVi)

Mobile Network

1 x B-Key M.2 (3042) for 3G/4G,
1 x SIM Slot

I/O interface

USB

1 x USB Type-C3.2 Gen2 (10 Gbps),
4 x USB3.2 Gen2 (10 Gbps), 2 x USB2.0

Serial Port

1 x RS232, 1 x RS232/422/485

Audio

1 x MIC-IN, 1 x AUDIO-OUT

Button

1 x Power on, 1 x CLR-CMOS

Antenna

2 x Connector for Wi-Fi/BT
2 x Connector for 3G/4G (Reserved)

System

TPM

Optional: TPM2.0

Watchdog Timer

Yes

Auto Power On

Yes

RTC

Set up independently every day, a week as a cycle

Power Requirement

DC-IN, 19 V/3.42 A

Dimensions

200 mm x 150 mm x 40 mm (7.87" x 5.90" x 1.57")

Construction

Metal, Grey

Operating System

Windows 11 (64bit) /Linux Ubuntu (64bit)

Operating Temperature

0°C ~45°C (32°F~113°F) @0.7m/s Air Flow

Humidity

95% @ 45°C (non-condensing)

Certifications

CE, FCC Class B, UKCA

Manufacturer Part No:
DF612-i5
Brand:
Giada
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCGDA20012
Product Model:
DF612-i5
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
