Sintrones ABOX 5000 FanlessPC, i5-6500TE Industrial grades. 4 x RS-232/422/485, 8 x GPI and 4 x GPO,4 x GbE LAN, SATA Dual SATA Hot Swappable, 9-36VDC Input Fast Expansible Slot support PCI-E, USB, SMBus, GPIO

PB Tech price
PB Tech price
AUD $ 1,904 .38
$ 1,904 .38

Out of stock

Sintrones ABOX 5000 FanlessPC, i5-6500TE Industrial grades. 4 x RS-232/422/485, 8 x GPI and 4 x GPO,4 x GbE LAN, SATA Dual SATA Hot Swappable, 9-36VDC Input Fast Expansible Slot support PCI-E, USB, SMBus, GPIO

  • Brand: Sintrones
  • MPN: ABOX-5000P-i5
  • Part #: IPCSTNABX50002
  • UPC:
PB Tech price
AUD $ 1,904 .38 $ 1,904 .38


Delivery: Out of stock
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info

Features

Intel 6th-Gen Skylake Core i5 CPU w/ 4 GbE/ 4 ISO COM/ 2 DP/ VGA/ 4 USB 3.0/ Fast Expansible Slot/ 9-36V Fanless Computer

- 4 x RS-232/422/485 with 1.5KVrms isolated
- 8 x GPI and 4 x GPO with 1.5KVrms isolated
- 4 x GbE LAN (optional for 4 x PoE and additional 4 x GbE/PoE)
- Dual Hot Swappable SATA Storage
- 9-36VDC Input and Operating Temp.: -40 ~ 70ºC
- Fast Expansible Slot support PCI-E, USB, SMBus, GPIO and SATA



Specifications

SPECIFICATIONS SYSTEM

CPU

Intel Gen6 Core i5-6500TE (6M Cache 2.3GHz up to 3.3GHz)
*Use only with Intel C236

Memory

2 x DDR4 2133 MHz SO-DIMM up to 32GB

Chipset

Intel® C236 / Q170 Platform Controller Hub

LAN Chipset

3 x Intel i210-AT and 1 x i219LM (support iAMT) Gb/s
Ethernet Controllers Onboard Support PXE and WOL

Watchdog

1 ~ 255 Level Reset

TPM

2.0

I/O

Serial Port

4 x RS-232/422/485 w/1.5KVrms isolation (Auto Direction Control)

USB Port

4 x USB 3.0 Ports

LAN

4 x RJ45 Ports for GbE (Optional for 4 x POE 15.4W per port)

Video Port

2 x Display Port and 1 x VGA Port (Triple Independent Display)

DIO Port

8 x GPI and 4 x GPO connector w/1.5KVrms isolation

Audio

1 x Line-out and 1 x Mic-in (Line-in Optional)

Expansion Bus

3 Full and 1 Half Mini-PCIe Slot (2 x SIM Card Sockets for 3G/LTE)

FES Expansion

Support PCI-E Bus, USB Bus, SM Bus, GPIO and SATA Bus (Customized for Customer without NRE charge)

STORAGE

Type

1 x 2.5" drive bay for SATA Type Hard Disk Drive / SSD
1 x SATA DOM

POWER REQUIREMENT

Power Input

9V -36V DC Power Input

Power Protection

Automatics Recovery Short Circuit Protection

Power Management

Vehicle Power Ignition for Variety Vehicle

Power Off Control

Power off Delay Time Setting by Software and BIOS

Backup Battery

Internal Battery Kit for 10 Mins Operating (Optional)
Patent No. : M447854 - Build-in Battery

MECHANICAL & ENVIRONMENTAL

Dimensions (LxWxH)

240 x 226 x 79 mm

Mounting

Wall-mount

Weight

3860g (bare-bone)

Relative Humidity

10% RH - 90% RH (non-condensing)

Operating Temp.

-40ºC ~ 70°C (Default CPU 35 Watt)

Storage Temp.

-40 ~ 80°C

Certifications

CE, FCC Class A, E13

Patent No. (Taiwan)

M447854, M448011

ORDERING INFORMATION

Part Number

765000040000

Description

Intel 6th-Gen Skylake Core Xeon/i7/i5/i3 CPU w/ 4 GbE/ 4 ISO COM/ 2 DP/ VGA/ 4 USB 3.0/ Fast Expansible Slot/ 9-36V Fanless Computer

Manufacturer Part No:
ABOX-5000P-i5
Brand:
Product Type:
Industrial grades.
UPC
-
Product Family:
ABOX 5000 FanlessPC,
Shipping Weight:
1 kg
PB Part No:
IPCSTNABX50002
Product Model:
i5-6500TE
Warranty: 12 months *
