ATP FT32G0SD4APEBFC 32GB UHS-I SDXC, A1, U3 Memory Card
ATP FT32G0SD4APEBFC 32GB UHS-I SDXC, A1, U3 Memory Card
- Brand: ATP
- MPN: FT32G0SD4APEBFC-ABZ1
- Part #: MEMATP1004
- UPC:
- Brand: ATP
- MPN: FT32G0SD4APEBFC-ABZ1
- Part #: MEMATP1004
- UPC:
COMBO DEALS: Frequently Bought Together
UGREEN UG-80191 USB-C +USB-A To TF/SD 3.0 Multi Card Reader - For SD Micro SD SDHC SDXC MMC Card...
$13.60
$13.60
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial PCs & IoT
ATP FT32G0SD4APEBFC 32GB UHS-I SDXC, A1, U3 Memory Card
- Brand: ATP
- MPN: FT32G0SD4APEBFC-ABZ1
- Part #: MEMATP1004
Product URL: https://www.pbtech.com/product/MEMATP1004/ATP-FT32G0SD4APEBFC-32GB-UHS-I-SDXC-A1-U3-Memory-C
Features
- Compliant with SD Specification version 6.10
- LDPC Controller
- SiP (System-In-Package) process
- Water proof, Dust proof and ESD Resistant
- Advanced Static/Dynamic Wear-Leveling- 11K P/E cycles per block, low WAF
- Low Latency
- Data Integrity - Read retry & Auto-Read-Calibration (ARC)
- Data Integrity - Read Disturb Protector
- Data Integrity - Power failure protection
- Analysis method - SD Life monitor tool
- Analysis method - For SiP memory cards
- Non-CPRM support by default
- RoHS compliant
- CE & FCC & UKCA certification
- Controlled BOM
- Customized service: adjustable CID registers, firmware & setting and logo by projects
Specifications
Temperature
Operating
-25°C to 85°C (C-Temp.)
-40°C to 85°C (I-Temp.)
Non-Operating
-55°C to 90°C
Humidity
Operating
8% ~ 95% relative humidity, non-condensing
Non-Operating
8% ~ 95% relative humidity, non-condensing
Random Vibration Test
Non-Operating
10 ~ 2000Hz, 6Grms, 30min per axis
Bend Test
Non-Operating
10N to the center of the card, total 5 cycles
Torque Test
Non-Operating
0.15N-m or +/-2.5°
Salt Spray Test(MIL-STD-883G Method1009.8)
Non-Operating
35°C, Over 85% RH,3% Salt Concentration
Solar Radiation Test
Non-Operating
40°C, Irradiation 1000W/m2
UV Light Exposure Test(ISO 7816-1)
Non-Operating
254nm, 15Ws/cm2
Drop Test
Non-Operating
150cm/Free fall, total 6 drops
