ASUS ZenScreen MB16FC 16" WUXGA 16:10 Portable Monitor
- 1920X1200 - IPS Panel - Mini HDMI - USB-C x 2 - Auto Rotate
ASUS ZenScreen MB16FC 16" WUXGA 16:10 Portable Monitor
- 1920X1200 - IPS Panel - Mini HDMI - USB-C x 2 - Auto Rotate
- Brand: ASUS
- MPN: MB16FC
- Part #: MONASU72244
- UPC:
- Brand: ASUS
- MPN: MB16FC
- Part #: MONASU72244
- UPC:
Similar in-stock products available at PB Tech right now
Features
- 16-inch 16:10 1920x1200 resolution and an impressive 84% screen-to-body ratio brings you expansive view
- With Power Pass Through, the MB16FC portable monitor can be powered by a laptop, or deliver power to a laptop via pass-through charging
- Automatically sense its orientation and switch the monitor between landscape and portrait modes via DisplayWidget Center software
- ASUS Eye Care monitors feature TÜV Rheinland-certified Flicker-free and Low Blue Light technologies to ensure a comfortable viewing experience
- Rich connectivity with two full-function USB-C® ports plus a mini-HDMI® port
More immersive
Brings you a stunning 16:10 display that's both wider and more vibrant, supporting up to 1920x1200 resolution and an impressive 84% screen-to-body ratio. Enjoy an expansive, vivid view all packed into a sleek, lightweight extended portable monitor.
Power pass through
There is the two-way power delivery function built in. The MB16FC portable monitor can be powered by a laptop, or deliver power to a laptop via pass-through charging when plugged into a USB-C power bank or AC adapter and outlet*.
Note:
1. The connected adaptor will need to supply up to 80W to reach its maximum 65W Power Delivery
2. Suggest to use the in-box 30W adaptor to have Power Delivery support
One cable is all you need
MB16FC features rich connectivity with dual USB-C and mini-HDMI ports. A single USB-C cable* is all you need to duplicate or extend your laptop screen. USB-C handles both power and video signal transmission, so it's simply a matter of plug-and-play when it's time to level up your work efficiency.
Note* Need to check whether the USB-C port of your laptop supports DP Alt mode prior to use. Or You can use HDMI connectivity along with USB-C (DC-IN) as power input instead if your laptop does not support USB-C (DP)
Automatic screen orientation
When connected to a Windows PC, the ASUS DisplayWidget Center tool* enables MB16FC to sense its orientation and automatically switches the display between landscape and portrait modes.
*Software required. Auto-rotate function works with both Windows and MAC OS.
ASUS Eye Care
ASUS Ultra-Low Blue Light technology reduces potentially harmful blue light emissions and includes additional features that are beneficial to those who spend long hours in front of a display.
LOW BLUE LIGHT
The ASUS Blue Light Filter protects viewers from harmful blue light. This feature offers a range of filter settings that are easy to access via the intuitive OSD menu.
ZenScreen MB16FC has passed stringent performance tests and is certified by TÜV Rheinland laboratories, a global provider of technical, safety, and certification services.
FLICKER FREE TECHNOLOGY
TÜV Rheinland-certified ASUS Flicker Free technology eliminates flicker, ensuring comfortable viewing experiences. This technology helps minimize eyestrain and other ailments typically associated with extended hours of viewing.
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Portable Monitors
AOC 16T20 15.6" FHD Portable Monitor 1920x1080 - Mini HDMI - USB...
ASUS ZenScreen MB169CK 15.6" FHD Portable Monitor - 1920x1080 -...
MSI Pro MP161 E2 15.6" FHD Portable Monitor 1920x1080 - IPS -...
Lenovo ThinkVision M15 15.6" FHD Mobile Monitor 1920x1080 - IPS -...
ASUS ZenScreen MB27ACF 27" QHD Portable Monitor with C-Clamp...
ASUS ZenScreen MB16FC 16" WUXGA 16:10 Portable Monitor - 1920X1200 - IPS Panel - Mini HDMI - USB-C x 2 - Auto Rotate
- Brand: ASUS
- MPN: MB16FC
- Part #: MONASU72244
Product URL: https://www.pbtech.com/product/MONASU72244/ASUS-ZenScreen-MB16FC-16-WUXGA-1610-Portable-Monit
Features
- 16-inch 16:10 1920x1200 resolution and an impressive 84% screen-to-body ratio brings you expansive view
- With Power Pass Through, the MB16FC portable monitor can be powered by a laptop, or deliver power to a laptop via pass-through charging
- Automatically sense its orientation and switch the monitor between landscape and portrait modes via DisplayWidget Center software
- ASUS Eye Care monitors feature TÜV Rheinland-certified Flicker-free and Low Blue Light technologies to ensure a comfortable viewing experience
- Rich connectivity with two full-function USB-C® ports plus a mini-HDMI® port
More immersive
Brings you a stunning 16:10 display that's both wider and more vibrant, supporting up to 1920x1200 resolution and an impressive 84% screen-to-body ratio. Enjoy an expansive, vivid view all packed into a sleek, lightweight extended portable monitor.
Power pass through
There is the two-way power delivery function built in. The MB16FC portable monitor can be powered by a laptop, or deliver power to a laptop via pass-through charging when plugged into a USB-C power bank or AC adapter and outlet*.
Note:
1. The connected adaptor will need to supply up to 80W to reach its maximum 65W Power Delivery
2. Suggest to use the in-box 30W adaptor to have Power Delivery support
One cable is all you need
MB16FC features rich connectivity with dual USB-C and mini-HDMI ports. A single USB-C cable* is all you need to duplicate or extend your laptop screen. USB-C handles both power and video signal transmission, so it's simply a matter of plug-and-play when it's time to level up your work efficiency.
Note* Need to check whether the USB-C port of your laptop supports DP Alt mode prior to use. Or You can use HDMI connectivity along with USB-C (DC-IN) as power input instead if your laptop does not support USB-C (DP)
Automatic screen orientation
When connected to a Windows PC, the ASUS DisplayWidget Center tool* enables MB16FC to sense its orientation and automatically switches the display between landscape and portrait modes.
*Software required. Auto-rotate function works with both Windows and MAC OS.
ASUS Eye Care
ASUS Ultra-Low Blue Light technology reduces potentially harmful blue light emissions and includes additional features that are beneficial to those who spend long hours in front of a display.
LOW BLUE LIGHT
The ASUS Blue Light Filter protects viewers from harmful blue light. This feature offers a range of filter settings that are easy to access via the intuitive OSD menu.
ZenScreen MB16FC has passed stringent performance tests and is certified by TÜV Rheinland laboratories, a global provider of technical, safety, and certification services.
FLICKER FREE TECHNOLOGY
TÜV Rheinland-certified ASUS Flicker Free technology eliminates flicker, ensuring comfortable viewing experiences. This technology helps minimize eyestrain and other ailments typically associated with extended hours of viewing.
Specifications
Model
ZenScreen MB16FC
Display
Panel Size (inch)
16
Aspect Ratio
16:10
Display Viewing Area (H x V)
344.68 x 215.42mm
Display Surface
Anti-Glare
Backlight Type
LED
Panel Type
IPS
Viewing Angle (CR≧10, H/V)
178°/ 178°
Pixel Pitch
0.179mm
Resolution
1920x1200
Brightness (Typ.)
300cd/㎡
Contrast Ratio (Typ.)
1000:1
Display Colors
16.7M
Response Time
5ms(GTG)
Refresh Rate (Max)
75Hz
Flicker-free
Yes
Features
Trace Free Technology
Yes
SPLENDID Technology
Yes
Color Temp. Selection
Yes (4 modes)
Auto Rotation
Yes, supported by DisplayWidget Center
QuickFit
Yes (Photo/Alighment Grid)
HDCP
Yes, 1.4
DisplayWidget
Yes, DisplayWidget Center
Low Blue Light
Yes
Power Pass-through
Max. 65W
Audio
Speaker
No
I/O Ports
USB-C
x 2 (DP Alt Mode)
Mini HDMI
x 1
Earphone Jack
Yes
Digital Signal Frequency
USB-C
30~100KHZ (H) / 59~75Hz(V)
Mini HDMI
30~100KHZ (H) / 59~75Hz(V)
Power Consumption
Power Consumption
≤5.62W
Power Saving Mode
<0.5W
Power Off Mode
<0.3W
Voltage
100-240V, 50/60Hz
Mechanical Design
Height Adjustment
No
Kensington Lock
Yes
1/4" Tripod Socket
Yes
Dimensions (Esti.)
Phys. Dimension (W x H x D)
35.8 x 24.6 x 1.1 cm (14.09" x 9.69" x 0.43")
Box Dimension (W x H x D)
44.3 x 31.8 x 9.0 cm (17.44" x 12.52" x 3.54")
Weight (Esti.)
Net Weight
0.90 kg (1.98 lbs)
Gross Weight
1.90 kg (4.19 lbs)
Certificate
Certificate
FSC MIX
TÜV Low Blue Light
TÜV Flicker-free
Energy Star
