Huawei eKit AR720 Layer 3 Access Router

8x 1Gbe LAN - 2x Combo-WAN (1GbE + 2x SFP) - 2x USB - 1U Rackmount

PB Tech price
PB Tech price
AUD $ 1,051 .52
$ 1,051 .52

Out of stock

Huawei eKit AR720 Layer 3 Access Router

8x 1Gbe LAN - 2x Combo-WAN (1GbE + 2x SFP) - 2x USB - 1U Rackmount

  • Brand: Huawei
  • MPN: 02354GBG-001
  • Part #: NETHUA02354
  • UPC: 886598225793
PB Tech price
AUD $ 1,051 .52 $ 1,051 .52
Out of stock
Delivery: Out of stock
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Huawei
  • MPN: 02354GBG-001
  • Part #: NETHUA02354
  • UPC: 886598225793

Wireless Technology

Not Specified

Ethernet Ports Per Unit

12

USB Ports

Yes

Wireless Transmission Speed

Not Specified

WiFi Bands

N/A

Cellular Connectivity

N/A

HyperFibre Compatible

No

Coverage Area

Not Specified

View full specs
Returns & Warranty Bulk Quote Print Page

Features

Forwarding performance: 9 Mpps to 25 Mpps | Number of connected terminals: 700 | Fixed WAN ports: 2 x GE combo ports | Fixed LAN ports: 8 x GE ports (can be switched to WAN ports) | Dimensions (H x W x D): 43.6 mm x 442 mm x 220 mm

High performance

- ARM-based multi-core processors and nonblocking switching architecture
- Twice the industry average performance, ensuring a low latency for key services

High reliability

- Link backup for enterprise services, enhancing service access reliability
- Fault detection and determination in milliseconds, minimizing the service

Service convergence

- Integration of functions such as routing, switching, VPN, security, and WLAN, enabling diversified enterprise services, saving space,
and reducing TCO

Security

- Built-in firewall, IPS, URL filtering, and multiple VPN technologies, providing comprehensive security protection capabilities

Specifications

Forwarding performance

9 Mpps to 25 Mpps

Number of connected terminals

700

Installation type

Rack,Work bench,Against the wall

Dimensions without packaging (H x W x D) [mm(in.)]

- Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 220.4 mm (1.75 in. x 17.4 in. x 8.68 in.) - Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 225.2 mm (1.75 in. x 17.4 in. x 8.87 in.)

Chassis height [U]

1

Dimensions with packaging (H x W x D) [mm(in.)]

90 mm x 570 mm x 390 mm (3.54 in. x 22.44 in. x 15.35 in.)

Weight with packaging [kg(lb)]

4.6 (10.12)

Weight without packaging [kg(lb)]

3.2 (7.04)

RTC

Supported

Typical power consumption [W]

28

Maximum power consumption [W]

33

Power supply mode

AC built-in

Number of power modules

1

Input voltage range [V]

90 V to 264 V, 47 Hz to 63 Hz

Maximum output power [W]

70

Safety regulation certification

IEC/EN/UL 60950-1 IEC/EN/UL 62368-1 GB 4943.1

Types of fans

Built-in

Number of fan modules

1

Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F) Note: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

LAN ports

8 x GE electrical interfaces

WAN ports

2 x GE combo

Airflow

Left-to-right airflow

Manufacturer Part No:
02354GBG-001
Brand:
Huawei
Product Type:
Access Router
UPC
886598225793
Product Family:
eKit
Shipping Weight:
4.5 kg
PB Part No:
NETHUA02354
Product Model:
AR720
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
Provide feedback on product content: If this product page is missing key information or you spotted a mistake please let us know.
