LevelOne GTU-5211 52-Port Gigabit Ethernet Switch 48x 1GbE RJ45 4x 10GbE SFP+
- Brand: LevelOne
- MPN: GTU-5211
- Part #: NETLEL1006

Product URL: https://www.pbtech.com/product/NETLEL1006/LevelOne-GTU-5211-52-Port-Gigabit-Ethernet-Switch
Features
GTU-5211 52-Port Unmanaged Gigabit Ethernet Switch, 48 x Gigabit RJ45, 4 x 10GbE SFP+
- 48 Gigabit Ethernet ports and 4 10-Gigabit SFP+ slots
- Supports 32K MAC address auto-learning and auto-aging
- 10K jumbo frames to increase data transfer rates
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
Gigabit Speeds: Take Your Data to the Next Level
The GTU-5211 is a 52-port Gigabit Ethernet Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 176Gbps and bring Gigabit speeds all the way to your computers.
Bandwidth hungry? Not a problem.
What happens when you have several users accessing multimedia applications all at the same time? No need to worry as GTU-5211 allows you to move large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files over the network instantly and without lag.
Plug and Play, Flexible and Easy
The GTU-5211 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.
Specifications
General
Brand
LevelOne
Manufacturer Part Number
GTU-5211
Color
Black
Grade
Commercial
PoE supported
No
Manageable
No
Fanless
No
Concurrent ports
Total 52.00
Weight
3.389 kg
Dimensions (W x D x H)
440 x 290 x 44.5 mm
Performance
Switching capacity
176 Gbps
System specifications
Power supply
100-240 VAC, 50-60 Hz
Data rate
10Gbps, 1Gbps
Power supply included
Yes
Power consumption
48 W
MTBF
43,800 hrs
Heat dissipation
163.8 (Btu/H)
Port Configuration
48x 10/100/1000 Mbps RJ-45 copper ports, 4x 10GbE SFP+ Slot
Standard
IEEE 802.3 10-BASE-T (Ethernet)
IEEE 802.3u 100-BASE-TX (Fast Ethernet)
IEEE 802.3ab 1000BASE-T (Gigabit Ethernet)
IEEE 802.3z 1000BASE-X (Gigabit Ethernet)
IEEE 802.3x Flow Control (full-duplex flow control)
IEEE 802.3az: Energy Efficient Ethernet
Acoustic noise (dB)
30 dB
Mount
19" rack mount, Desk mount
Flash memory size
16 MB
RAM size
256 MB
MAC address table
32 K
Jumbo frame (KB)
10 KB
Indicators
Power, Link/Ack
Packet buffer
16 Mbits
Backplane (Gbps)
176
Others
Approval and compliance
CE
UKCA
FCC Part 15, Subpart B Class B
RoHS
Operating humidity
10% RH ~ 90% RH
Operating temperature
0°C ~ 45°C
Storage humidity
5% RH ~ 95% RH
Storage temperature
-40°C ~ 70°C
Package contents
GTU-5211
Power Cord
19" Rack Mount Kit
Quick Installation Guide
Declaration of Conformity
