FS Intel E10GSFPSRX Compatible 10GBASE-SR SFP+ 850nm 300m DOM Duplex LC MMF Optical Transceiver Module
Out of stock
FS Intel E10GSFPSRX Compatible 10GBASE-SR SFP+ 850nm 300m DOM Duplex LC MMF Optical Transceiver Module
- Brand: FS
- MPN: FS-71385
- Part #: NETLTE2011
- UPC:
- Brand: FS
- MPN: FS-71385
- Part #: NETLTE2011
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Transceivers
FS Intel E10GSFPSRX Compatible 10GBASE-SR SFP+ 850nm 300m DOM Duplex LC MMF Optical Transceiver Module
- Brand: FS
- MPN: FS-71385
- Part #: NETLTE2011
Product URL: https://www.pbtech.com/product/NETLTE2011/FS-Intel-E10GSFPSRX-Compatible-10GBASE-SR-SFP-850n
Features
Intel E10GSFPSRX Compatible 10GBASE-SR SFP+ Transceiver Module (MMF, 850nm, 300m, LC, DOM)
Intel E10GSFPSRX compatible SFP+ transceiver supports up to 400m link lengths over OM4 MMF (300m over OM3 MMF) via an LC duplex connector. This transceiver is compliant with SFF-8431, SFF-8432 and IEEE 802.3ae standards and for seamless interoperability in multivendor environments. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption and high speed, this 10G SFP+ transceiver is ideal for data centres, enterprise wiring closets, service provider transport applications, Radio & Baseband Units, etc.

10G Connectivity for Data Center
Featured with 1W low-power, high-density and high-speed, the SFP+ transceiver offers a popular way to help you quickly ramp up to 10G transmission.

Tailored Excellence with TO-Can Packaging
Taking TO-can package design, the transceiver has great reliability, airtightness, and heat dissipation performance, ideal for telecom &data centre applications.

Tested in Host Devices for Proven Interoperability
Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.

Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
- Optical Spectrum Test: No Packet Loss & CRC
- Eye Pattern Test: Mask Margin >20%
- Bit Error Rate Test: BER 1E-12
- Temperature Test: 0~70°C

Certifications
Fully certified to meet strict international safety and quality standards for the industry.
Specifications
Intel Compatible
E10GSFPSRX
Form Factor
SFP+
Max. Data Rate
10.3125Gbps
Wavelength
850nm
Max. Transmission Distance
300m@OM3/400m@OM4
Connector
Duplex LC
Media
MMF
Transmitter Type
VCSEL
Receiver Type
PIN
TX Power
-7.3~-1dBm
Receiver Sensitivity
< -11.1dBm
Power Budget
3.8dB
Receiver Overload
-1dBm
Max. Power Consumption
≤1W
Extinction Ratio
>3dB
DDM/DOM
Supported
Operating Temperature
0 to 70°C (32 to 158°F)
Core Size
50/125µm
Modulation
NRZ
Protocols
IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI
