FS Cisco compatible QSFP-H40G-CU2M DAC 2m (7ft) 40G QSFP+ Passive Direct Attach Copper Cable
Out of stock
FS Cisco compatible QSFP-H40G-CU2M DAC 2m (7ft) 40G QSFP+ Passive Direct Attach Copper Cable
- Brand: FS
- MPN: FS-48948
- Part #: NETLTE2074
- UPC:
- Brand: FS
- MPN: FS-48948
- Part #: NETLTE2074
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Transceivers
FS Cisco compatible QSFP-H40G-CU2M DAC 2m (7ft) 40G QSFP+ Passive Direct Attach Copper Cable
- Brand: FS
- MPN: FS-48948
- Part #: NETLTE2074
Product URL: https://www.pbtech.com/product/NETLTE2074/FS-Cisco-compatible-QSFP-H40G-CU2M-DAC-2m-7ft-40G
Features
Cisco QSFP-H40G-CU2M Compatible 40G QSFP+ DAC Cable (2-metre, Passive, QSFP+ to QSFP+, 30AWG)
The Cisco QSFP-H40G-CU2M Compatible 40G QSFP+ Passive Direct Attach Copper Twinax Cable is designed for use in 40GBASE Ethernet. It provides a QSFP+ to QSFP+ copper direct-attach solution. This cable is compliant with IEEE 802.3ba Ethernet standard and QSFP MSA Compliant.
With these features, this easy to install, high speed, cost-effective direct attach copper twinax cable is suitable for short-distance connectivity within a rack or between adjacent racks in data centres.
- Max. Power Consumption 0.5W
- Tested in Targeted Switches for Superior Performance, Quality, and Reliability
- Minimum Bend Radius 35mm for Flexible Routing
- Simplifies the Patching and Offers a Cost-effective Way for Short Links
- Hot Pluggable QSFP+ MSA Compliant
- Low Insertion Loss and Ultra-low Crosstalk for Improved Performance
- RoHS Compliant

Connectivity Solutions
40G to 40G Direct Connection Solution

Flexible Routing for Modern Data Centers
With a minimum bend radius of 35mm, it allows flexible routing without compromising signal integrity, making it ideal for short-distance connections within or between racks.

Low Power Consumption for Energy-saving
Direct attach copper is suitable for very short links and offer a cost-effective way to establish a 40-Gigabit link between QSFP+ 40G ports within racks and across adjacent racks.
- ≤0.5W: Lower Power Consumption
- Copper Cable: to Save OPEX
- 35mm Minimum: Bend Radius for Easy Cabling

Tested in Host Devices for Proven Interoperability
Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.

Certifications
Fully certified to meet strict international safety and quality standards for the industry.

Note:
1. FS Box does not currently support changing H3C and HPE compatibility for DAC cables.
2. The FS P/N is changed from QSFP-PC02 to QSFP-40G-PC02, but the product is the same.
Specifications
Product Type
Passive Direct Attach Copper (DAC) cable
MPN
48948
Cisco Compatible
QSFP-H40G-CU2M
Connector Type
QSFP+ to QSFP+
Max Data Rate
40Gbps
Minimum Bend Radius
35mm
Wire AWG
30AWG
Cable Length
2m (6.56ft)
Jacket Material
PVC (OFNR)
Temperature
0 to 70°C (32 to 158°F)
Protocols
SFF-8436, QSFP+ MSA and IEEE 802.3ba
