FS 7m (23ft) Cisco SFP-H10GB-ACU7M Compatible 10G SFP+ Active Direct Attach Copper Twinax Cable
- MPN: FS-36609
- Part #: NETLTE2080
Product URL: https://www.pbtech.com/product/NETLTE2080/FS-7m-23ft-Cisco-SFP-H10GB-ACU7M-Compatible-10G-SF
Features
Cisco SFP-H10GB-ACU7M Compatible 10G SFP+ DAC Twinax Cable (7-metre, Active, SFP+ to SFP+, 26AWG)
The 10G SFP+ Active Direct Attach Copper Twinax Cable is designed for use in 10GBASE Ethernet. This cable is compliant with IEEE 802.3, SFF-8431, and SFP+ MSA. With these features, this easy to install, high speed, cost-effective direct attach copper twinax cable is suitable for short-distance connectivity within a rack or between adjacent racks in data centres.
- Max. Power Consumption 0.5W
- Tested in Targeted Switches for Superior Performance, Quality, and Reliability
- Minimum Bend Radius 30mm for Flexible Routing
- Simplifies the Patching and Offers a Cost-effective Way for Short Links
- Hot Pluggable SFP+ MSA Compliant
- Low Insertion Loss and Ultra-low Crosstalk for Improved Performance
- RoHS Compliant

Connectivity Solutions

Low Power Consumption for Energy-saving
Direct attach copper is suitable for very short links and offer a cost-effective way to establish a 10-Gigabit link between SFP+ 10G ports within racks and across adjacent racks.
- <0.5W: Lower Power Consumption
- Copper Cable: to Save OPEX
- 23mm Minimum: Bend Radius for Easy Cabling

Tested in Host Devices for Proven Interoperability
Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.

Certifications
Fully certified to meet strict international safety and quality standards for the industry.

Note:
1. The FS P/N is changed from SFPP-AC07 to SFP-10G-AC07, but the product is the same.
Specifications
Cisco Compatible
SFP-H10GB-ACU7M
Connector Type
SFP+ to SFP+
Max Data Rate
10Gbps
Minimum Bend Radius
30mm
Wire AWG
26AWG
Cable Length
7m (22.97ft)
Jacket Material
PVC (OFNR)
Cable Type
Active Twinax
Temperature
0 to 70°C (32 to 158°F)
Power Consumption
≤0.5W
Power Supply
3.3V
Protocols
1x InfiniBand QDR, DDR, SDR, 10 Gigabit Ethernet, Fibre Channel
