FS FS-104216 0.5m (2ft) Cisco QSFP-100G-CU0.5M Compatible 100G QSFP28 4 x 25G NRZ Passive Direct Attach Copper Twinax

Cisco QSFP-100G-CU0.5M Compatible 100G QSFP28 DAC Cable (0.5-metre, Passive, QSFP28 to QSFP28, 30AWG)

The 100G QSFP28 Passive Direct Attach Copper Twinax Cable offers a cost-effective solution for establishing a 100-Gigabit link between switches' QSFP-100G ports within racks and across adjacent racks. This Direct Attach Copper cable provides low insertion loss and ultra-low crosstalk. It complies with IEEE 802.3, SFF-8662, and hot-pluggable QSFP28 MSA standards, ensuring compatibility and reliability.With its power-efficiency, this cable delivers reliable connectivity for short-distance interconnects. It enables higher port bandwidth, density and configurability at a low cost and reduced power requirement in the data centres.

- Max. Power Consumption 0.5W
- Tested in Switches for Superior Performance and Reliability
- Minimum Bend Radius 33.5mm for Flexible Routing
- 4x 25G-NRZ to 4x 25G-NRZ
- Simplifies the Patching and Offers a Cost-effective Way for Short Links
- Hot Pluggable QSFP28 MSA Compliant
- Low Insertion Loss and Ultra-low Crosstalk for Improved Performance
- Class 1 FDA Laser Safety and RoHS-6 Compliant

Low Power Consumption for Energy-saving

Direct attach copper is suitable for very short links and offer a cost-effective way to establish a 100-Gigabit link between QSFP-100G ports within racks and across adjacent racks.

- ≤0.5W: Lower Power Consumption
- Copper Cable: to Save OPEX
- 33.5mm Minimum:Bend Radius for Easy Cabling

Tested in Host Devices for Proven Interoperability

Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.

Reliable Test Result

Professional testing ensures stable and reliable optics with verified hardware and software compatibility, covering connectivity, BER and key operating parameters.

Easy Plug-and-Play

This cable offers hot pluggable functionality for enhanced uptime and improved serviceability. It's compliant with the industry-standard QSFP28 MSA, ensuring compatibility across various devices and systems.

Target Markets & Applications

Communications
Network Interface Cards (NICs), Switches, Servers

Data
Data Center, High Performance Computing, Server

Industrial & Instrumentation
Industrial Controls & Instruments

Certifications

Fully certified to meet strict international safety and quality standards for the industry.

Note:

1. FS Box does not currently support changing H3C and HPE compatibility for DAC cables.
2. The FS P/N is changed from Q28-PC005 to QSFP-100G-PC005.
