FS Fortinet FG-TRAN-LX Compatible 1000BASE-LX SFP 1310nm 10km Duplex LC/UPC SMF Transceiver Module
Out of stock
FS Fortinet FG-TRAN-LX Compatible 1000BASE-LX SFP 1310nm 10km Duplex LC/UPC SMF Transceiver Module
- Brand: FS
- MPN: FS-248881
- Part #: NETLTE2102
- UPC:
- Brand: FS
- MPN: FS-248881
- Part #: NETLTE2102
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Transceivers
FS Fortinet FG-TRAN-LX Compatible 1000BASE-LX SFP 1310nm 10km Duplex LC/UPC SMF Transceiver Module
- Brand: FS
- MPN: FS-248881
- Part #: NETLTE2102
Product URL: https://www.pbtech.com/product/NETLTE2102/FS-Fortinet-FG-TRAN-LX-Compatible-1000BASE-LX-SFP
Features
Fortinet FG-TRAN-LX Compatible 1000BASE-LX/LH SFP Transceiver Module (SMF, 1310nm, 550m/10km, LC)
Fortinet FG-TRAN-LX compatible SFP transceiver supports up to 10km link lengths over LC duplex SMF fibre. Each SFP transceiver module is individually tested to be used on a series of Cisco switches, routers, servers, network interface card (NICs) etc.Featuring low power consumption, the hot swappable 1G SFP transceiver is ideal for Internet Service Provider (ISP) Gigabit Ethernet communication links, Enterprise LAN & SAN Networks, Data Center LAN & SAN Networks and other optical links.
- Hot Pluggable SFP MSA Compliant to Maximize Uptime and Simplify Maintenance
- Max. Power Consumption 1W Allowing for Prolonged Service Life
- Commercial Temperature Range 0 to 70°C (32 to 158°F)
- Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
- Compliant to IEEE 802.3z Gigabit Ethernet
- Class 1 FDA Laser Safety and RoHS Compliant
- Tested in Targeted Switches for Superior Performance, Quality, and Reliability

1G Connectivity for Data Center
Featured with low power consumption, the SFP transceivers provide a cost-effective solution for Gigabit Ethernet applications.

Tested in Host Devices for Proven Interoperability
Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.
- Hot Pluggable SFP MSA Compliant
- Digital Optical Monitoring
- Class 1 FDA Laser Safety

Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
- Optical Spectrum Test: No Packet Loss & CRC
- Eye Pattern Test: Mask Margin >20%
- Bit Error Rate Test: BER 1E-12
- Temperature Test: 0~70°C

Product Certifications & Compliance
Fully certified to meet strict international safety and quality standards for the industry.

Specifications
Fortinet Compatible
FG-TRAN-LX
Form Factor
SFP
Max. Data Rate
1.25Gbps
Wavelength
1310nm
Max. Cable Distance
10km@SMF
Connector
Duplex LC
Media
SMF
Transmitter Type
FP
Receiver Type
PIN
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
TX Power
-9.5~-3dBm
Receiver Sensitivity
< -20dBm
Power Consumption
≤1W
Receiver Overload
-3dBm
Bit Error Ratio (BER)
1E-12
Extinction Ratio
>9dB
EMC (Electro Magnetic Compatibility)
Supported
MTBF (LX)
4,761,904 Hours
Protocols
IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant
