Luxul AMS-1816P AV Series 18-port/16-port PoE+ Switch Managed Switch

PB Tech price

AUD $ 1,071 .73

$ 1,071 .73

Luxul AMS-1816P AV Series 18-port/16-port PoE+ Switch Managed Switch

Brand: Luxul
MPN: AMS-1816P
Part #: NETLXL1012
UPC:

PB Tech price

AUD $ 1,071 .73

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 10 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Luxul
MPN: AMS-1816P
Part #: NETLXL1012
UPC:

Be the first to review this product

10 Gigabit

10 Gigabit Ports

0 Ports

Form Factor

Not Specified

Management Level

Managed

Number of Ports

18 Ports

PoE Ports

16 Ports

PoE Budget

185 Watts

View full specs

Returns & Warranty Bulk Quote Print Page

Features

The AMS-1816P is an 18-port Gigabit swtich that easily functions on its own or provides cost effective expandability via its two Gigabit SFP uplink ports to other Luxul switches in your AV rack. The 16 PoE+ ports provide a robust 185W power budget and simple power management to automation touch panels, security cameras, and other PoE powered devices. The compact rack-mountable design, selectable green/blue front facing LEDs, and variable speed fans ensure aesthetic and quiet operation. The AMS-1816P provides simple installation with powerfully intuitive management, including L2/L3 switching, 802.1Q VLAN support with trunking, and QoS prioritization support.

- PoE Self-Healing with auto-recovery and power scheduling
- 16 Gigabit 802.3af/at PoE+ ports (185W power budget)
- Two Gigabit SFP ports
- Full layer 2/3 support
- 802.1Q VLAN (with trunking) and QoS support
- User selected green and blue front facing LEDs
- Variable speed fans for quiet operation
- Plug-and-play installation with intuitive management
- Simple power management of PoE enabled devices
- Compact design in standard 19" rack-mount enclosure

The AMS-1816P can easily be installed in a standard 19" rack

Specifications

MPN

AMS-1816P

Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.1D, IEEE 802.3x, IEEE 802.1P, IEEE 802.1Q, IEEE 802.1X

Interface

- RJ-45
- 10 Base-T: Cat.5 UTP/STP
- 100 Base-TX: Cat.5 UTP/STP
- 1000 Base-T: Cat.5, Cat.5e, or Cat.6 UTP/STP
- Gigabit fiber uplinks on SFP ports
- Ethernet cable recognition for straight-through or crossover cables

Surge Protection

The RJ45 port surge protection is tested to: EN61000-4-5 (for RJ45 port, surge 6KV)

Power Budget

185 watts

Max Power Consumption

250W

Power

Internal switched power, AC 100-240V, 50-60Hz input

VLAN

- 802.1Q max 4094 VIDs & VLAN trunking
- Supports 1 management VLAN

Quality of Service (QoS)

- 4 queues per port
- Queue handling: Strict, Weighted Round Robin (WRR)
- CoS based on DCSP, 802.1P
- Port-based bandwidth control

Operating Temperature

32°F to 104°F (0°C to 40°C)

Operating Humidity

10% to 90% (non-condensing)

Dimensions LxWxH in. (mm)

17.4"(442) x 8.3"(211) x 1.75"\"(44.5)

Weight lbs (kg)

5.95 (2.7)

Certification

FCC, IC, CE-EMC, CE-LVD, and RoHS

Manufacturer Part No:

AMS-1816P

Brand:

Luxul

Product Type:

UPC

Product Family:

Shipping Weight:

1.01 kg

PB Part No:

NETLXL1012

Product Model:

AMS-1816P

Warranty: 12 months *
