MikroTik RBwAPG-60ad-SA RBwAPG-60ad-SA 60 GHz Access Point
- Brand: MikroTik
- MPN: RBwAPG-60ad-SA
- Part #: NETMKT1298

Product URL: https://www.pbtech.com/product/NETMKT1298/MikroTik-RBwAPG-60ad-SA-RBwAPG-60ad-SA-60-GHz-Acce
Features
wAP 60Gx3 AP
60 GHz Base Station with Phase array 180° beamforming Integrated antenna, specially designed for Multipoint connections.
The wAP 60Gx3 AP is a new access point model for the 60 GHz spectrum. Compared with the regular wAP 60G AP, this new model has a completely new antenna array, with support for a much wider angle of coverage and is optimized specifically for multipoint operation.
The 96 antenna elements work with beamforming technology to provide connectivity for up to eight 60 GHz client devices at the same time, in a 180 degree field of view. Build a cost effective point to multipoint setup in the clean 60 GHz wireless spectrum, at a fraction of the cost.
Two wAP 60Gx3 AP units can be used in point-to-point configurations as well.
Specifications
Specifications
Product code
RBwAPG-60ad-SA
Architecture
ARM 32bit
CPU
IPQ-4019
CPU core count
4
CPU nominal frequency
716 MHz
Dimensions
185 x 85 x 30 mm
RouterOS license
4
Operating System
RouterOS
Size of RAM
256 MB
Storage size
16 MB
Storage type
FLASH
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 70°C
IPsec hardware acceleration
Yes
Powering
Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-57 V
Max power consumption
11 W
FAN count
Passive
PoE in
802.3af/at
PoE in input Voltage
20-57 V
Ethernet
10/100/1000 Ethernet ports
1
Certification & Approvals
Certification
CE, EAC, ROHS
IP
IP54
