MikroTik GPERx6 Outdoor Gigabit Passive Ethernet Repeater with 1x PoE-In, 2x PoE-Out and 3x SFP+ Ports
MikroTik GPERx6 Outdoor Gigabit Passive Ethernet Repeater with 1x PoE-In, 2x PoE-Out and 3x SFP+ Ports
- Brand: MikroTik
- MPN: CSS606-1G-2Gi-3S+OUT
- Part #: NETMKT1525
- UPC:
- Brand: MikroTik
- MPN: CSS606-1G-2Gi-3S+OUT
- Part #: NETMKT1525
- UPC:
Features
GPERx6
Cut the cable clutter - extend power and fiber together, anywhere - with a single hybrid cable. At the far end, the GPERx6 splits it all neatly: SFP+ for further long-distance uplinks, PoE-out for powering other switches or access points, and DC outputs for IoT gear or specialized devices.
- 3x 10G SFP+ Ports
- 3x Gigabit Ethernet Ports (1x PoE-in, 2x PoE-out)
- Heavy-duty IP66 enclosure
- Flexible powering, PoE-in, 2x PoE-out, DC jack, 3x DC-out
- A dedicated 10G switch chip
Built for the toughest deployments
The outdoors can be brutal: blistering heat, freezing cold, wind, rain. The elements attack your gear. The wiring is a nightmare. The GPERx6 solves both problems - a rugged, outdoor-ready switch that cuts cable clutter and keeps deployments simple
Hybrid cable advantage
With hybrid fiber + copper cables, the GPERx6 becomes a power-and-data lifeline:
- Fiber strands carry your high-speed uplink;
- Copper conductors deliver DC power;
- At the far end, the GPERx6 splits it all:
SFP+ uplinks for data;
PoE-out for cameras or access points;
DC-out for IoT devices or special hardware.
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Other Networking
Abeeway DEABE502-19-8AS LoRaWAN AS923 Compact GPS IoT Tracker
Ubiquiti UniFi USW-Flex-Utility Outdoor Weatherproof Enclosure...
Elgato Network Dock for Stream Deck
StarTech.com RJ45COVER 100 Pack RJ45 Dust Covers - Reusable RJ45...
PoE World PS-24v120w 24V 5A 120W AC/DC power supply
MikroTik GPERx6 Outdoor Gigabit Passive Ethernet Repeater with 1x PoE-In, 2x PoE-Out and 3x SFP+ Ports
- Brand: MikroTik
- MPN: CSS606-1G-2Gi-3S+OUT
- Part #: NETMKT1525
Product URL: https://www.pbtech.com/product/NETMKT1525/MikroTik-GPERx6-Outdoor-Gigabit-Passive-Ethernet-R
Features
GPERx6
Cut the cable clutter - extend power and fiber together, anywhere - with a single hybrid cable. At the far end, the GPERx6 splits it all neatly: SFP+ for further long-distance uplinks, PoE-out for powering other switches or access points, and DC outputs for IoT gear or specialized devices.
- 3x 10G SFP+ Ports
- 3x Gigabit Ethernet Ports (1x PoE-in, 2x PoE-out)
- Heavy-duty IP66 enclosure
- Flexible powering, PoE-in, 2x PoE-out, DC jack, 3x DC-out
- A dedicated 10G switch chip
Built for the toughest deployments
The outdoors can be brutal: blistering heat, freezing cold, wind, rain. The elements attack your gear. The wiring is a nightmare. The GPERx6 solves both problems - a rugged, outdoor-ready switch that cuts cable clutter and keeps deployments simple
Hybrid cable advantage
With hybrid fiber + copper cables, the GPERx6 becomes a power-and-data lifeline:
- Fiber strands carry your high-speed uplink;
- Copper conductors deliver DC power;
- At the far end, the GPERx6 splits it all:
SFP+ uplinks for data;
PoE-out for cameras or access points;
DC-out for IoT devices or special hardware.
Specifications
Product code
CSS606-1G-2Gi-3S+OUT
Number of 1G Ethernet ports
3
Number of 10G SFP+ ports
3
Switch chip model
88E6193X
Certification
IP66
Dimensions
406 x 116 x 76 mm
Operating system
SwOS
Operating temparature
-40°C to +70°C
Number of DC inputs
2 (2-pin screw terminal, PoE-In)
2-pin screw terminal input Voltage
12-57 V
PoE-In input Voltage
42-57 V
PoE-In
802.3 bt
PoE-Out
Passive PoE up to 57V (Ether2- Ether3)
Max out per port output (input < 30 V)
1.2 A
Max out per port output (input > 30 V)
0.625 A
Max total out
2.4 A
Number of DC-out ports
3, DC1-DC3 Max total out 3.6 A
Max power consumption (without attachments)
6 W
Max power consumption
160 W
