Robustel B056704 Industrial Router

Robustel B056704 Industrial Dual SIM LTE Router, GPS, WiFi, 5x Ethernet, VPN, PoE (PD)

The R1520 router from Robustel is a versatile 4G router with 5 x Ethernet ports, GPS and E-mark certification for in-vehicle use.

WIFI, GPS Cat 4, Dual SIM, 5xETH, 1xRS232, 1xRS485, 1xDI, 1xDO,1xAI, 1xUSB2.0, 9-36VDC Power input as well as PoE powered

- Cost-effective & high performance 3G/4G router
- Rugged design with wide range 9 to 36V DC power
- E-mark certification for in-vehicle use
- Optically isolated digital IO
- 10-bit Analogue interface for direct sensor connections
- Supports Dual SIMs & Wifi/Ethernet as WAN
- Cellular keep-alive and fast failover
- Extensive range of software "apps" for enhanced functionality
- RobustVPN - hosted service providing a "fixed IP" router
- IPsec/OpenVPN/GRE/L2TP/PPTP/DMVPN supported
- Extensive global certifications
- Powered via PoE or power pack

The R1520 router from Robustel is a versatile 4G router with 5 x Ethernet ports, GPS and E-mark certification for in-vehicle use. Other hardware features include optically isolated digital inputs and outputs as well as a 10-bit analogue input capable of interfacing directly with sensors in the range of 0 to 24Vdc or 0 to 20mA.

R1520 also has a 2-wire RS485 interface for connection to legacy instruments with full support for Modbus. The RS232 port features RTS/CTS lines so the product can accommodate applications that require hardware handshaking.

Despite being cost-effective, the R1520 is a powerful router with high packet-forwarding capability - way beyond the typical requirements of LTE CAT4 networks. The Linux based Operating System, RobustOS, has been developed entirely in-house which leads to a very high standard of technical support and infrequent firmware updates due to modular nature of the OS. Many unique software innovations are built on top of RobustOS, these include:

- RobustVPN: highly flexible hosted VPN service so customers can easily enjoy a "fixed IP router"
- Data-Guard: invaluable failsafe in case of a system failure and runaway data usage
- Smart Reboot: SMS tool to push roaming SIMs from a non-working to working state
- Sniffer: run a Wireshark trace directly on the router for invaluable diagnostic information. Customers can also easily write their own applications using the extensive SDK supplied free of charge.
- RCMS is Robustel's free router monitoring service that is fully compatible with the R1520. It allows customers to see a location overview of their routers quickly and simply on a map.Features such as data usage, signal strength, current network and much more can then be viewed on a per router. Over-the-air updates are supported for Firmware, router configuration and Apps serving as essential 'insurance' if anything was not quite right during deployment.

Application Example

APPLICATION EXAMPLE

In-Vehicle Connectivity Hub
Provides secure LTE backhaul and onboard Wi-Fi; segment ops vs passenger traffic; optional GNSS supports location reporting; RCMS centralizes updates and management.

Intelligent Traffic Systems
Backhaul controller and signage data to your platform via encrypted tunnels; dual-SIM failover maintains reachability; manage configurations and updates centrally.

Digital Signage & Screens
Delivers reliable IP backhaul from players to your CMS, keeping content updates flowing during outages and enabling centralized monitoring and troubleshooting.
