StarTech.com D01ML55P-FIBER-MEDIA Gigabit Fiber to RJ45 Media Converter
Out of stock
StarTech.com D01ML55P-FIBER-MEDIA Gigabit Fiber to RJ45 Media Converter
- Brand: StarTech.com
- MPN: D01ML55P-FIBER-MEDIA
- Part #: NETSTT6328720
- UPC: 65030909822
- Brand: StarTech.com
- MPN: D01ML55P-FIBER-MEDIA
- Part #: NETSTT6328720
- UPC: 65030909822
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Media Converters
StarTech.com D01ML55P-FIBER-MEDIA Gigabit Fiber to RJ45 Media Converter
- Brand: StarTech.com
- MPN: D01ML55P-FIBER-MEDIA
- Part #: NETSTT6328720
- UPC:65030909822
Product URL: https://www.pbtech.com/product/NETSTT6328720/StarTechcom-D01ML55P-FIBER-MEDIA-Gigabit-Fiber-to
Features
This compact Gigabit Fiber to Ethernet Media Converter enables Cat6 or similar cabling to be upgraded to an EMI-free fiber connection. The TAA-compliant adapter is PoE powered, making it a perfect choice when external power options are unavailable.
Simplified Installation
The unmanaged fiber media converter features a plug-and-play design that does not require additional software or settings to be changed. The metal housing features an IP20 rating and is an all-in-one construction with integrated LC fiber and RJ45 ports. The RJ45 side features a metal tab to ensure a reliable and secure fit and prevent accidental disconnections.
Short & Long Range Fiber
- LC slot compatible w/Single-Mode (10km) & Multi-Mode (800m)
- Single speed 1Gbps for both fiber and RJ-45 ports
- Status LEDs including LFPT (Link Fault Pass-Through) enables IT admins to monitor network connectivity
Network Features
The PoE media converter is designed to work seamlessly with any networking equipment that is PoE-capable and supports the 802.3af standard or higher. It comes equipped with a range of PoE protection features, including Over Voltage Protection (OVP), Over Current Protection (OCP), Over Temperature Protection (OTP), and 2KV Surge Protection. The LC slot is compatible with Single-Mode (10km) and Multimode (800m) fiber cables up to 1Gbps. A spring-loaded tab protects the port when not in use. The converter supports LFPT (Link Fault Pass-Through), allowing IT administrators to monitor and assess network connectivity at a glance based on the LED behavior.
Compatibility
This LAN-to-fiber converter is ideal for upgrading computers, switches, routers, or other equipment from copper to fiber. It suits various applications, including field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking. Experience reliable connectivity with EMI immunity over long distances with this compact (3.2x0.8x0.7in/82.39x20x17.5mm) and power-efficient (2.5W max) dongle.
Applications
- Upgrade PoE capable computers, switches, routers, or other equipment to fiber
- Suitable for on-site network troubleshooting, field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking
Specifications
Connector(s)
Connector A
1 - LC
Connector B
1 - RJ-45
Hardware
PoE
Yes
Industry Standards
IEEE 802.3ab (1000BASE-T)
IEEE 802.3z (1000BASE-LX)
IEEE 802.3af (PoE)
Chipset ID
Marvell - 88E1512
Indicators
LED Indicators
1 - Power
Solid Green: Module On
Off: Module Off
1 - Link/ACT
Solid Green: 1000Mbps
Blinking Green: Activity
Off: Disconnected
1 - Fiber
Solid Blue: Connected
Off: Disconnected
Performance
Compatible Networks
1000 Mbps (1 Gbps)
Auto-Negotiation
Yes
Auto MDIX
Yes
MTBF
374,141 hours at 25ºC (77ºF)
Physical Characteristics
Color
Silver
Product Height
0.7 in [1.7 cm]
Product Length
0.8 in [2.0 cm]
Weight of Product
1.5 oz [42.0 g]
Product Width
3.2 in [8.2 cm]
Material
Metal and Plastic
Power
Power Source
PoE-Powered
Input Voltage
30 - 57V DC
Plug Type
RJ45 Male
Power Consumption (In Watts)
2.5W
Environmental
Operating Temperature
0°C to 55°C (32°F to 131°F)
Humidity
5~85% RH
Special Notes / Requirements
Note
The D01ML55P-FIBER-MEDIA expands toward the rear. Depending on the port spacing of your device, this may obstruct adjacent ports. Please refer to the technical diagram for precise dimensions and to ensure compatibility with your port spacing requirements.
What's in the Box
Included in Package
1 - Media Converter
1 - Product Documentation
