Supermicro PWS-350-1H 350W 1U Fixed Power Supply

80 Plus Platinum

PB Tech price

AUD $ 207 .27

$ 207 .27

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

Supermicro PWS-350-1H 350W 1U Fixed Power Supply

80 Plus Platinum

Brand: Supermicro
MPN: PWS-350-1H
Part #: PSUSPM35102
UPC: 672042188079

PB Tech price

AUD $ 207 .27

Out of stock

Delivery: Out of stock

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Supermicro
MPN: PWS-350-1H
Part #: PSUSPM35102
UPC: 672042188079

Be the first to review this product

Max Output Power

350W

PSU Form Factor

80 Plus Rating

Platinum

Modular

Colour

Grey

16-Pin GPU Connector

PSU Length

180mm

PSU ATX Version

Not Specified

View full specs

Returns & Warranty Bulk Quote Print Page

Features

Supermicro 350W Multi-output Power Supply (PWS-350-1H)

- Designed for Mainstream 1U Server
- 24 Pin ATX Output
- 80 Plus Platinum Efficiency
- Supermicro Certified

The Supermicro PWS-350-1H is an 80 Plus Platinum level power supply capable of continuously supplying 350W output power at 94% efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages and a quiet fan to keep it cool under heavy loads. This power supply is designed to not only provide you reliable power to your 1U server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 200,000 hours and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. All materials contained comply with RoHS requirements and are certified by Supermicro.

Cables Included:

- 1x 24 Pin ATX (Motherboard)
- 1x 8 Pin 12V (CPU)
- 1x (4+4) 8 Pin 12V (CPU)
- 2x 4 Pin Legacy HDD

Specifications

Total Power Output

350W

Type

Single

Type of Power Supply

Power Supply

Form Factor

Dimension (W x H x L)

100 x 40 x 180mm

+5V

15A

+12V

29A

+3.3V

12A

5V Standby

Input Voltage Range

100-240Vac

Input Frequency Range

50-60Hz

Input Current Range

5 - 2.5A

Output Type

24Pin ATX Cable Output

8Pin / 4Pin (12V) Connector

Both

PFC

Yes

Voltage / Current

Energy Efficiency

94% Peak

80 Plus Certification

80 Plus Platinum

Validated Systems

SYS-1019C-FHTN8,
SYS-1019D-4C-FHN13TP,
SYS-1019D-FHN13TP,
SYS-5018R-M,
SYS-5019C-M,
SYS-5019C-M4L,
SYS-5019C-MHN2,
SYS-5019P-M,
SYS-5019P-MT,
SYS-5019S-M,
SYS-5019S-M-G1585L,
SYS-5019S-M2,
SYS-5019S-ML,
SYS-5019S-MN4,
SYS-5019S-MT

Validated Chassis

CSE-512F-350B1,
CSE-513BTQC-350B,
CSE-513BTQC-350WB,
CSE-515-350,
CSE-813MFTQC-350CB,
CSE-813MFTQC-350CB2

Manufacturer Part No:

PWS-350-1H

Brand:

Supermicro

Product Type:

Power Supply

UPC

672042188079

Product Family:

Shipping Weight:

1.355 kg

PB Part No:

PSUSPM35102

Product Model:

PWS-350-1H

Warranty: 36 months *
