Creality Sermoon P1 All-in-One 3D Scanner

Creality Sermoon P1 All-in-One 3D Scanner

- Multi-Line Scanning for Speed & Detail: 22+7+1 Blue Laser Lines + Dual NIR VCSEL ensure fast, complete capture. Handles complex shapes, holes, and fine details efficiently, minimizing rescans.

- Versatile Size Range: Accurately scan objects from 5 mm³ to 4000 mm³, from small precision parts to large assemblies, with a single device.

- High Precision for Demanding Work: 0.02mm + 0.06mm/m volumetric accuracy delivers reliable, dimensionally accurate models for engineering, inspection, and digital archiving.

- 3 Modes for Maximum Flexibility: Use standalone, wirelessly, or wired to match your task. Enjoy full portability for fieldwork or stable real-time streaming to your PC.

- Hardware Built for Performance: A high-performance processor (CPU/GPU/FPGA), 6-inch HD screen, 24GB RAM, 256GB storage, and Wi-Fi 7, enabling high-precision scanning and data post-processing without a computer enable smooth, real-time processing of high-resolution scans without slowdowns.

- Uninterrupted Operation: Two hot-swappable 3300mAh batteries provide extended, continuous scanning. Swap batteries without powering down for non-stop workflows.

Scan. Process. Export - All in one Device.

An all-in-one 3D scanning workflow in a single device. With advanced laser & structured light systems and powerful onboard computing, Sermoon P1 enables high-precision scanning and processing-no PC required.

Scan Anywhere. No Limits.

Built for tight, hard-to-reach spaces, Sermoon P1 enables flexible, cable-free scanning where traditional setups fall short. Capture high-quality data on-site-fast, efficient, and without constraints.

Triple Work Modes, Flexible Operation

Switch seamlessly between Standalone, Wired PC, and Wireless PC modes -- adapt easily to any scanning environment or workflow.

0.02 mm + 0.06 mm/m, Reliable Consistent Accuracy

Designed for repeatable, reliable results in professional workflows such as reverse engineering and automotive customization.

Hybrid Light Source System

Featuring 22 + 7 + 1 blue laser lines + NIR structured light

*Sermoon P1 adapts to different surfaces and materials, Markerless Scanning - Coming in May.

Single-line Deep Hole Scanning

For measuring deep holes and hard-to-reach areas.

7 Parallel-line Fine Scanning

For swift detail capture of intricate features and complex structures.

22 Cross-line Fast Scanning

For efficient scanning to quickly capture the geometry and dimensions of large parts.

NIR Markerless Scanning

Fast, marker-free scanning for large objects and the human body.

*Test based on a 28.68 mm diameter pipe, with a measured depth of 172.2 mm

Single-Line Laser, Mastering Deep Holes(Up to depth-to-diameter ratio 6:1)

The P1 single-line laser deep-hole scanning mode captures accurate 3D data from hard-to-reach areas such as deep holes, narrow gaps, and recesses. It supports scanning narrow holes with a depth-to-diameter ratio of up to 6:1, delivering more complete 3D data for design, inspection, analysis, and beyond.

Innovative 4-lens

High-speed data acquisition ensures smooth,accurate real-time reconstruction - even during complex scans.

- Blue Laser Mode:up to 60 FPS (Standalone) / 100 FPS (PC)
- Infrared Mode:up to 18 FPS (Standalone) / 30 FPS (PC)

Fast Scanning, Smooth Capture

High-performance Qualcomm Processor

Powered by a Qualcomm high-performance processor with CPU/GPU/FPGA acceleration for fast, real-time scanning and data processing.

Ultra-Fast Memory & Storage

24GB LPDDR5X RAM and 256GB UFS 4.0 ROM

Wi-Fi 7, Fast & Stable Connectivity

Built-in Wi-Fi 7 and advanced lossless compression algorithms ensure faster, safer, and more reliable data transfer.

6-Inch HD Touchscreen - Clear & Intuitive

A 6-inch Full HD display with crisp visuals and an 160° wide viewing angle, ensuring clear visibility even outdoors. Scan, process, and preview-all on a single device.

Swappable Dual- Battery Design

Equipped with two swappable batteries (1 installed, 1 included separately). And comes with an extra battery pack enables seamless, uninterrupted operation.

Power That Keeps You Going

A smart power-saving system automatically enters sleep mode to extend battery life.

Fast Charging

Charges to 80% in just 50 minutes, making outdoor scanning more convenient and worry-free. Each battery features a Type-C charging port for independent charging.

Efficient Scanning at Large FOV

A larger single-frame FOV reduces marker requirements while improving tracking stability and scanning efficiency.

- Blue Laser Max: 380 × 365 mm @ 550 mm
- Infrared Max: 1245 × 754 mm @ 1000 mm (1-minute full-body scan)

Wide Scanning Range, All-in-One Efficiency

By combining blue laser lines and NIR structured light, the Sermoon P1 supports a wide scanning range - from 5*5*5 mm³ up to 4000*4000*4000 mm³.

Full Color Texture Scanning

Equipped with a high-performance Qualcomm ISP chip and a full-color RGB camera with global shutter, enhanced by auxiliary lighting, the P1 delivers richer, more realistic textures.

12 Dual-color LED Fill Lights

Blue light is used for blue laser scanning. White light enhances color texture brightness.

Qualcomm ISP Color Mapping

Advanced color mapping algorithms ensure accurate and vivid color reproduction.

AI Temperature Compensation - Driven Stabilization

An AI-based temperature compensation algorithm works with efficient thermal design to ensure stable output and consistent scanning during extended use.

Powerful and User-Friendly Onboard Software

An all-in-one onboard software integrates Calibration, Scanning, Point-cloud Fusion, Mesh Editing, Mulit-scan Merging, enbling complete model processing directly on the device.

Intuitive Interaction
A clean, visual interface guides users from scanning to model creation with ease.

Modular & Flexible Design
Customizable workflow adapts to different scanning needs and user preferences.

One-Click OTA Updates
Regular over-the-air updates ensure your device stays current with the latest features.

Seamless Compatibility with Inspection, Design, and 3D Printing Software

Scan data can be easily imported into mainstream reverse engi-neering, inspection, and design software such as QuickSurface and Geomagic Design X, streamlining workflows.
