JBL PRO CONTROL23-1 2 WAY 100W 3IN DUAL IMP SPEAKER W/BRK BLACK

JBL PRO CONTROL23-1 2 WAY 100W 3IN DUAL IMP SPEAKER W/BRK BLACK

  • Brand: JBL PRO
  • MPN: CONTROL23-1
  • Part #: SPKJBL1102
  • UPC:
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 09 Jul
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
Sign in to your commercial account or apply online now to view the price and order this product
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: JBL PRO
  • MPN: CONTROL23-1
  • Part #: SPKJBL1102
  • UPC:

Colour

Black

Sound Mode

N/A

Power Output (RMS)

100 Watts

Wireless Technology

N/A

3.5mm Connector

None

Optical Connector

None

RCA Connector

None

TRS Connector

N/A

View full specs
Returns & Warranty Bulk Quote Print Page

Features

Ultra-Compact Indoor/Outdoor Background/Foreground Speaker

The Control® 23-1 is a two-way 3" speaker with rich sonic character, wide coverage, consistent dispersion, versatile mounting, and a contemporary high-design look that fits into a wide range of decors. This makes Control 23-1 an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality compact indoor/outdoor foreground/background music (and/or paging) speaker is required. NOTE: Priced as each but must be sold as pairs, so two must be ordered.

Built-in InvisiBall mounting hardware

Provides a high degree of both vertical and horizontal rotation, and a high degree of theft deterrence

Weather resistant enclosure and transducers

In addiotion to the driver designs contributing toward a high degree of weather resistance, the cabinet provides excellent endurance against sun, salt and moisture. Grilles are heavily zinc-plated and finished in toughm high-grade powder coating for rust resistance.

Contemporary high-design look

Fits into a wide rance of decors

Rich sonic character

High fidelity sound character with broad frequency response of 70 Hz - 20Hz

Wide 100 x 100 coverage

Allows for fewer speakers to be used, making for a simpler and less expensive installed

Built in 15 Watt 70V/100V multi tap transformer

For operation on distributed speaker lines

Specifications

Frequency Range (-10dB)

70 Hz to 20 kHz

Frequency Response (±3 dB)

95 Hz - 19 kHz

Power Rating

100W Continuous Program (2 hrs)50 W (200W peak), Continuous Pink Noise (2 hrs) 40 W (160W peak) Continuous Pink Noise (100 hrs)

Maximum Input Voltage

17.2 V RMS (2 hrs), 34.4 V peak

Maximum SPL (1m)

103 dB ave. Continuous Pink Noise (109 dB peak)

Sensitivity

86 dB, 1W/1m (ave. 100 Hz - 10 kHz)

Coverage Angle

100°H x 100°V

Directivity Factor (Q)

5.8 (averaged 1kHz - 16kHz)

Directivity Index (DI)

7.2 dB (averaged 1kHz - 16kHz)

Impedance

8 ohms (THRU setting)

Crossover Type

2nd order low-pass, 2nd order high-pass

Transformer Taps

70V: 15W, 7.5W, 3.7W, 1.8W100V: 15W, 7.5W, 3.7W Insertion Loss <0.43 dB at any tap settingThru Setting: 8O nominal

Recommended Protective High-Pass

70 Hz high-pass (24 dB/oct) (for 8O operation and for all 70V/100V taps settings).

Drivers

LF: 76 mm (3.0 in), woven-fiberglass cone with pure butyl rubber surround with Weather-Edge frame protection, high-temp Kapton™ voice coil former, high-temp voice coil wire, optimized cone geometry, linear suspension spider, and FEA optimized motor structure.
HF: 13 mm (0.5 in) PEI diaphragm, low-viscosity ferro-magnetic fluid, and lightweight Kapton™ voice coil former.

Enclosure

High Impact Polystyrene (HIPS), painted with highly-UV resistant paint on white (-WH) version for maximum UV fade resistance.

Grille

Highly zinc-plated, finished in durable TGIC polyester powdercoating. MTC-23WMG-1 (&-WH) available with WeatherMax™ multi-layer foam and tight-weave mesh vapor barrier backing.

Mounting Hardware

InvisiBall™ wall-mounting system included. Two 6 mm attachment points (on top and bottom) for optional MTC-23UB-1 (&-WH) U-bracket. Secondary safety attachment loop point on back panel.

Outdoor Capability

IP-44 per IEC529 (IP-55 when installed with the optional MTC-23WMG-1 WeatherMax™ grille and either MTC-PC2 or MTC-PC3 panel cover.) Exceeds MilSpec 810 for humidity, salt-spray, temperature & UV. Passes MilStd-202F for salt spray and ASTM G85 for acid-air plus salt spray. Optional MTC-23WMG-1 WeatherMax™ grille for breaking up driving rain and for especially difficult environments.

Input Connectors

Screw-down terminal strip, zinc-plated copper based, nickel-plated metal screws and washers. Accepts up to 9 mm outside 4 mm inside open lugs (#6, #8, or #10 lug), plus bare wire (up to 12 AWG / 2.5 mm2). Optional MTC-PC2 and MTC-PC3 protective panel covers available to provide sealed entrance for additional weather protection.

Agency Rating

ROHS-compliant; Transformer UL Recognized per UL1876

Colour

Black

Dimensions (H x W x D)

200 x 141 x 111 mm (7.9 x 5.6 x 4.4 in); 141 mm (5.6 in) deep total when mounted on InvisiBall wall-mount bracket.

Net Weight

1.8 kg (4.0 lbs)

Included Accessories

InvisiBall™ wall-mounting system), 4 mm x 80 mm hex key

Manufacturer Part No:
CONTROL23-1
Brand:
JBL PRO
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
5 kg
PB Part No:
SPKJBL1102
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
Provide feedback on product content: If this product page is missing key information or you spotted a mistake please let us know.
