Advantech PCIE-1154-BE PCI Express x4, 4-Port USB 3.0 Host Adapter Card

Normally $262.37
Normally $262.37
You save $10
You save $10
AUD $ 251 .66
$ 251 .66
$251.66  +GST
$251.66

Advantech PCIE-1154-BE PCI Express x4, 4-Port USB 3.0 Host Adapter Card

  • Brand: Advantech
  • MPN: PCIE-1154-BE
  • Part #: IPCAVH221053
  • UPC:
Normally $262.37
Normally $262.37
You save $10
You save $10
PB Tech price
AUD $ 251 .66 $ 251 .66


Delivery: Order now and it ships on 25 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$251.66  +GST
$251.66

Features

- Four independent USB 3.0 controllers - Renesas µPD720202
- PCI Express Gen2 x4 interface, up to 2.0 GB/s
- eFuse power protection
- Protective shell prevents damage to components
- Supports Microsoft Windows 10

For more information: https://advdownload.advantech.com/productfile/PIS/PCIE-1154/file/PCIE-1154_1158_DS(102621)20211028180258.pdf

Specifications

MPN

PCIE-1154-BE (Preliminary)
4-port PCIe USB Vision Frame Grabber

USB

Interface

PCI Express x4

Host Bus

4-lane Gen 2.0 PCIe interface, compliant with
PCI Express Base Specification, Revision 2.0

Controller

Renesas µPD720202, Compliant with USB 3.0
Specification and Intel® xHCI Specification,
Revision 1.0

Max Current

900 mA maximum per port

Data Transfer Rate

SuperSpeed; High Speed; Full Speed;
Low Speed

Power

5 VDC power output, max. 4.5W per port

Power Requirements

Input Voltage

12 VDC direct from PCIe slot (limited to PCIe design) or AT/ATX system power input

Overload Current Protection

Device auto recover after eFuse tripped when rated currents > 2A

Environment

Operating Temperature

0 ~ 60 °C (32 ~ 140 °F)

Storage Temperature

-20 ~ 80 °C (-4 ~ 176 °F)

Operating Humidity

5 ~ 95% RH

Mechanics

Dimensions (W x D)

153 x 106 mm (6.02 x 4.17 in)

Net Weight

300 g (.66 lb)

Certification

Compliance

FCC CE Class A

Operating System

OS

Microsoft Windows 10

Manufacturer Part No:
PCIE-1154-BE
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
IPCAVH221053
Product Model:
PCIE-1154-BE
Warranty: 12 months *
