Advantech PCIE-1154-BE PCI Express x4, 4-Port USB 3.0 Host Adapter Card
- Brand: Advantech
- MPN: PCIE-1154-BE
- Part #: IPCAVH221053

Product URL: https://www.pbtech.com/au/product/IPCAVH221053/Advantech-PCIE-1154-BE-PCI-Express-x4-4-Port-USB-3
Features
- Four independent USB 3.0 controllers - Renesas µPD720202
- PCI Express Gen2 x4 interface, up to 2.0 GB/s
- eFuse power protection
- Protective shell prevents damage to components
- Supports Microsoft Windows 10
For more information: https://advdownload.advantech.com/productfile/PIS/PCIE-1154/file/PCIE-1154_1158_DS(102621)20211028180258.pdf
Specifications
MPN
PCIE-1154-BE (Preliminary)
4-port PCIe USB Vision Frame Grabber
USB
Interface
PCI Express x4
Host Bus
4-lane Gen 2.0 PCIe interface, compliant with
PCI Express Base Specification, Revision 2.0
Controller
Renesas µPD720202, Compliant with USB 3.0
Specification and Intel® xHCI Specification,
Revision 1.0
Max Current
900 mA maximum per port
Data Transfer Rate
SuperSpeed; High Speed; Full Speed;
Low Speed
Power
5 VDC power output, max. 4.5W per port
Power Requirements
Input Voltage
12 VDC direct from PCIe slot (limited to PCIe design) or AT/ATX system power input
Overload Current Protection
Device auto recover after eFuse tripped when rated currents > 2A
Environment
Operating Temperature
0 ~ 60 °C (32 ~ 140 °F)
Storage Temperature
-20 ~ 80 °C (-4 ~ 176 °F)
Operating Humidity
5 ~ 95% RH
Mechanics
Dimensions (W x D)
153 x 106 mm (6.02 x 4.17 in)
Net Weight
300 g (.66 lb)
Certification
Compliance
FCC CE Class A
Operating System
OS
Microsoft Windows 10
