StarTech.com 4K30-HDMI-CAPTURE USB 3.0 4K HDMI Video Capture Device
Out of stock
StarTech.com 4K30-HDMI-CAPTURE USB 3.0 4K HDMI Video Capture Device
- Brand: StarTech.com
- MPN: 4K30-HDMI-CAPTURE
- Part #: ADPSTT5567226
- UPC:
View all shipping info
- Brand: StarTech.com
- MPN: 4K30-HDMI-CAPTURE
- Part #: ADPSTT5567226
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular HDMI Adapters





StarTech.com 4K30-HDMI-CAPTURE USB 3.0 4K HDMI Video Capture Device
- Brand: StarTech.com
- MPN: 4K30-HDMI-CAPTURE
- Part #: ADPSTT5567226

Product URL: https://www.pbtech.com/au/product/ADPSTT5567226/StarTechcom-4K30-HDMI-CAPTURE-USB-30-4K-HDMI-Video
Features
This USB to HDMI video capture device enables HDMI A/V recording, at up to 4K 30Hz, to a USB-C or USB-A enabled computer.
Record 4K Video
The USB 3.2 Gen 1 (5Gbps) Capture Device enables recording of HDMI audio and video. Capture at up to 2160p 30fps, 1440p 60fps or 1080p 120fps with 16-bit PCM audio using third party software that supports DirectShow or QuickTime. Ideal for capturing the HDMI output of DSLR cameras, action cameras, webcams, and more.
USB Video Class
The capture device features USB Video Class (UVC), a video capture standard that's natively supported by Mac, Windows, and Ubuntu. USB bus-power and UVC facilitate plug and play installation. The included USB-A and USB-C cables let you connect to almost any host device running a supported operating system.
Capture or Stream
Record conference calls, presentations, security feeds, training videos, and more using third party software. Live stream content for community events, remote troubleshooting, or educational purposes on platforms supporting RTSP or RTMP communication protocols. The Capture Device works with Teams, Google Hangouts, Zoom, Adobe Connect, GoToMeeting, and more.
- PERFORMANCE: The HDMI Video Capture Device records up to 4K 30Hz HDMI | Captures up to 2160p 30fps, 1440p 60fps, or 1080p 120fps | 2ch 16 bit PCM audio support | 32KHz/44.1KHz/48KHz sampling rate | HDCP 1.4 compliant, does not capture protected content
- USB VIDEO CLASS: UVC ensures driverless, automatic install in Windows, macOS, and Ubuntu | The External USB Capture Card is compatible with DirectShow/QuickTime applications (OBS, Xsplit and VLC) | H.264/H.265 software encoding (MPEG4/MJPEG/YUY2)
- APPLICATIONS: Record conference calls, presentations, security feeds or training videos using 3rd party software | Live stream for education, corporate presentations, or houses of worship on platforms with RTSP/RTMP | Capture video camera, DSLR or webcams
- PORTABLE & BUS POWERED: Durable, compact, and lightweight aluminum video capture adapter | Ideal for media rooms, classrooms or recording studios| Connects directly to a laptop or desktop | 16inch (40cm) USB 3.2 Gen 1 USB-A and USB-C cables included
- COMPATIBILITY: This screen recorder works with Windows (7 & up), macOS (10.14 & up) and Ubuntu (20.04 & up) | Works w/ Thunderbolt 3 | Works with video editing and collaboration software such as Teams, Google Hangouts, Zoom, Adobe Connect, and GoToMeeting
Specifications
Connector(s)
Connector A
1 - HDMI
Connector B
1 - USB 3.2 USB Type Micro-B (10 pin, Gen 1, 5 Gbps)
Environmental
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
20 - 90%
Hardware
AV Input
HDMI
AV Output
USB
USB-C
Audio
Yes
Chipset ID
ITE - IT66021
ITE - IT9323
Performance
Maximum Digital Resolutions
3840 x 2160p @ 30fps
Audio Specifications
HDMI - 2 Channel Audio
Physical Characteristics
Color
Gray
Product Height
0.5 in [1.2 cm]
Product Length
2.9 in [7.3 cm]
Weight of Product
1.4 oz [41.0 g]
Product Width
1.7 in [4.4 cm]
Material
Aluminum
Cable Length
15.7 in [40 cm]
Power
Power Source
Bus Powered
Input Voltage
5
Input Current
300 mA
Power Consumption (In Watts)
1.5 W
Software
OS Compatibility
Windows 7, 8.1, 10, 11
macOS 10.14, 10.15, 11, 12
Ubuntu 20.04
