Features
Heavy Industrial Strength Aluminum Cast Frame. Black Design Patterned Treated Semi-Pressed Pulped Cone. Elevated Motor Structure Cooling Design. Oversized Spider. Black Coated Voice Coil for Higher Thermal Capability. Oversized Polished Black Chrome Finished Terminals. Polished Bumped Backplate. Klippel DA Optimized Motor and Suspension Symmetry.
Features
12" Dual 4-ohm High-Performance Subwoofer
1000W RMS/ 2000W MAX
Mounting Diameter: 11.25"
Mounting Depth: 6.6"
Voice Coil: 3"
Shorting Ring for lower Distortion
Dimensions
Specifications
Subwoofer Size
12"
Nominal Impedance (ohms)
4O
SPL (db)
86.9
Re (O)[series]
2O/4O
Qms
4.49
Qes
0.48
Qts
0.44
Fs-Free Air Resonance (Hz)
32.9
Vas (Liter)
44.2
Cms (mm/N)
0.12
Mms (g)
272.3
Sd (cm²)
0.053
BL (T*M)
25
Xmax - Inch(mm)
14
Pwr (W) NOM/MAX
1000/2000
Total Diameter
12.79" (325mm)
Mounting Diameter (inch/mm)
11.02" (280mm)
Screw Hole Diameter
0.26" (6.5mm)
Mounting Depth
5.98" (152mm)
Magnet Diameter (E)
7.89" (200.5mm)
Displacement (ft3/L)
0.094 ft3 (2.67L)
