RODE M3 Studio/Live Condenser Microphone
- Brand: RODE
- MPN: RODM3
- Part #: AUDROD1174
- UPC:698813001033

Product URL: https://www.pbtech.com/au/product/AUDROD1174/RODE-M3-StudioLive-Condenser-Microphone
Features
The M3 highly versatile end-address condenser microphone is designed to excel in a wide variety of recording situations in the studio, on stage or on location. Featuring an internally shock-mounted 1/2-inch condenser capsule, the M3 can either be powered by P48 phantom power or an internal 9V battery. It offers the versatility of a selectable pad (-10dB, -20dB) and high-pass filter (80Hz), making it ideal for recording everything from electric guitar to vocals to drums.
- Versatile end-address condenser microphone
- Cardioid polar pattern
- Robust, all-metal body
- Selectable pad (-10dB, -20dB) and high-pass filter (80Hz)
Battery or Phantom Powered Condenser
The M3 is capable of either 24-48V phantom power or internal 9V alkaline battery.
Cardioid Polar Pattern
The cardioid polar pattern reduces off-axis noise and maximizes gain.
-10dB and -20dB Pad Switch
A three position Pad switch maximizes headroom up to -10dB and -20dB.
High Pass Filter
A high pass filter switch eliminates noise and hum at the lower frequency range.
Specifications
Brand
RODE
MPN
RODM3
Weight
390g
Height
225mm
Width
33mm
Depth
33mm
Acoustic Principle
Pressure gradient
Active Electronics
JFET impedance converter with bipolar output buffer
Capsule
0.50"
Address Type
End
Frequency Range
40Hz - 20kHz (selectable high-pass filter @ 80Hz)
Output Impedance
200ohm
Maximum SPL
142dB SPL
Maximum Output Level
9.2mV (@ 1kHz, 1% THD into 1Kohm load)
Sensitivity
-40.0dB re 1 Volt/Pascal (6.30mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise Level (A-Weighted)
21dBA
Output Connection
XLR
Power Requirements
9V battery, P24 or P48
