Brocade GBIC SFP+ 16Gb SW LC 850nm Transceiver Module - SPN

PB Tech price
PB Tech price
$ 273 .31
 +GST
 $ 300 .64
 inc GST
$273.31  +GST
$300.64

Brocade GBIC SFP+ 16Gb SW LC 850nm Transceiver Module - SPN

  • Brand: Brocade
  • MPN: 57-0000088-01
  • Part #: BCD1003
  • UPC:
PB Tech price
$ 273 .31 $ 300 .64
 +GST  inc GST
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 16 Sep
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$273.31  +GST
$300.64
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Brocade
  • MPN: 57-0000088-01
  • Part #: BCD1003
  • UPC:
Returns & Warranty Bulk Quote Print Page

Features

Brocade 57-0000088-01 Compatible 16G Fibre Channel SWL SFP+ Transceiver (MMF, 850nm, 100m, LC, DOM)

This Brocade 57-0000088-01 compatible part is a small form factor pluggable SFP+ shortwave transceiver for 16G Fibre Channel (16GFC) applications. It supports links up to 100m over OM3 multimode fiber. This module features a highly reliable 850nm VCSEL transmitter and PIN photo-detector into a duplex LC optical connector. It is a multi-rated 850nm optical transceiver that supports 14.025/8.5/4.25G Fibre Channel specifications. This compatible 57-0000088-01 complies with Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) SFF-8431 Rev. 4.1 and SFF-8472 Rev. 11.0.  It has been programmed to ensure works with Brocade 16G SAN switches, routers, network interface cards (NICs) and other storage networking equipment.

- Functionally identical to Brocade 57-0000088-01
- Optical interface compliant to IEEE 802.3ae
- Electrical interface compliant to SFF-8431
- 850nm VCSEL transmitter, PIN photo-detector
- Built-in CDR with shut-off control
- Single +3.3V power supply
- Advanced firmware allow customer system

Specifications

Form Factor

SFP+

Data Rate

14.025 Gb/s

Wavelength

850 nm

Fiber Type

MMF

Max Distance

100m on OM3

Optical Components

VCSEL/PIN

Transmitter Power

-6.5 ~ -1.2 dBm

Extinction ratio

> 3.5 dB

Receiver Sensitivity

< -10.5 dBm

Receiver Overload

> -1 dBm

Connector

LC Duplex

Digital Diagnostic Monitoring

Yes

Operating temperature

0°C to 70°C

Storage temperature

-40°C to 85°C

Weight

0.03 kg

Application

High-speed storage area networks
- Switches and hubs
- Network interface cards
- Mass storage systems
- Host bus adapters
Tri-Rate 4G/8G/16G Fibre
Channel

Compliance

IEC/EN 61000-4-2,IEC-60825
FDA 21CFR 1040.10 and 1040.11
RoHS

Manufacturer Part No:
57-0000088-01
Brand:
Brocade
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.8 kg
PB Part No:
BCD1003
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
