StarTech.com 118-USBC-HDMI-VGADVI USB-C Video Adapter HDMI-VGA-DVI
StarTech.com 118-USBC-HDMI-VGADVI USB-C Video Adapter HDMI-VGA-DVI
- Brand: StarTech.com
- MPN: 118-USBC-HDMI-VGADVI
- Part #: CABSTT5544107
- UPC: 065030895583
View all shipping info
- Brand: StarTech.com
- MPN: 118-USBC-HDMI-VGADVI
- Part #: CABSTT5544107
- UPC: 065030895583
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular USB Adapters





StarTech.com 118-USBC-HDMI-VGADVI USB-C Video Adapter HDMI-VGA-DVI
- Brand: StarTech.com
- MPN: 118-USBC-HDMI-VGADVI
- Part #: CABSTT5544107
- UPC:065030895583

Product URL: https://www.pbtech.com/au/product/CABSTT5544107/StarTechcom-118-USBC-HDMI-VGADVI-USB-C-Video-Adapt?srsltid=AfmBOopFmzuH1f1JDRz8YQ5KVmIUtomn8Dc_eM4QQ88OZGMMbHhs7Ycf
Features
This USB-C™ multiport video adapter offers a durable and portable solution for connecting your USB Type-C device to a n HDMI, DVI, or VGA display.
Ultra HD 4K 60Hz Resolution
The HDMI 2.0b output supports up to 4K 60 Hz resolutions and HDR whereas VGA output supports up to 1920x1200 at 60 Hz, and the DVI-I output supports up to 1080p at 60 Hz. All the outputs offer compatibility with older displays supporting lower resolution. The adapter supports dual mirrored 1080p displays when using either VGA and HDMI or VGA and DVI-I monitor configurations.
Video Connectivity On The Go
Avoid the hassle of carrying different adapters with a USB Type-C Multiport Video Adapter. Connect a USB-C DisplayPort Alt-mode device to virtually any display. A durable aluminum enclosure helps the adapter withstand being carried in a travel bag between office, home, shared spaces, and during business travel.
Ease of Use
The USB Type-C Display Adapter is compatible with USB-C DisplayPort Alt-mode, Thunderbolt 3, Thunderbolt 4 Laptops, Ultrabooks, Chromebooks, and MacBooks. Plug and Play (PnP) capability allows you to quickly connect to devices running Windows, macOS, iPadOS, chromeOS, or Linux. The VGA and DVI outputs are compatible with screw locking cables ensuring a secure connection with displays and projectors. The 12 inch (30 cm) attached cable allows for flexibility in your setup and less strain on ports and connectors.
Specifications
Connector(s)
Connector A
1 - USB-C (24 pin) DisplayPort Alt Mode
Connector B
1 - VGA (15 pin, High Density D-Sub)
1 - 29 pin DVI-I (Dual Link) Female
1 - HDMI
Environmental
Operating Temperature
0? to 45? (32°F to 113°F)
Storage Temperature
-10? to 70? (14°F to 158°F)
Humidity
10% ~ 85 % RH
Hardware
Active or Passive Adapter
Active
AV Input
USB-C
AV Output
VGA
DVI-I (Digital Only) - Dual-Link
HDMI
Chipset ID
ITE - IT6224FN
Performance
Maximum Analog Resolutions
1920 x 1200 @ 60 Hz (VGA)
Maximum Digital Resolutions
3840 x 2160 @ 60 Hz (HDMI)
1920 x 1200 @ 60 Hz (DVI)
Wide Screen Supported
Yes
Audio Specifications
VGA - No Audio Support
DVI - No Audio Support
HDMI - 7.1 Channel Audio
Physical Characteristics
Color
Gray
Product Height
0.6 in [1.4 cm]
Product Length
3.3 in [8.5 cm]
Weight of Product
2.6 oz [75.0 g]
Product Width
1.8 in [4.5 cm]
Cable Length
11.8 in [300 mm]
Power
Power Source
Bus Powered
