StarTech.com DP12-CABLE-10FTW VESA Certified DisplayPort 1.2 Cable - 3m - White
StarTech.com DP12-CABLE-10FTW VESA Certified DisplayPort 1.2 Cable - 3m - White
- Brand: StarTech.com
- MPN: DP12-CABLE-10FTW
- Part #: CABSTT6331984
- UPC:
View all shipping info
- Brand: StarTech.com
- MPN: DP12-CABLE-10FTW
- Part #: CABSTT6331984
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular DisplayPort Cables





StarTech.com DP12-CABLE-10FTW VESA Certified DisplayPort 1.2 Cable - 3m - White
- Brand: StarTech.com
- MPN: DP12-CABLE-10FTW
- Part #: CABSTT6331984

Product URL: https://www.pbtech.com/au/product/CABSTT6331984/StarTechcom-DP12-CABLE-10FTW-VESA-Certified-Displa
Features
Connect a 4K UHD DisplayPort monitor to a host computer or MST hub, using this VESA-Certified DisplayPort 1.2 Cable. The connector markings enable quick visual identification, distinguishing this cable from other similar-looking or unmarked DP cables. Eliminate guesswork and always choose the appropriate cable to support full DP 1.2 capabilities.
Seamless Compatibility
For seamless operation between DisplayPort-enabled devices, the DisplayPort 1.2 Cable is VESA Certified for guaranteed DP 1.2 and backward compatibility. Certified cables provide consistent, reliable performance across multiple resolutions and refresh rates.
Durable Design
This DisplayPort cable features a flexible TPE outer jacket that routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching nickel-plated DP connectors attach securely to prevent accidental disconnection.
- HIGH PERFORMANCE: DP 1.2 Cable is designed for UHD-enabled DisplayPort devices; Choose the right DP cable at-a-glance with performance markings on connectors for quick and easy identification; Up to 21.6Gbps for seamless 4K 60Hz video
- VESA CERTIFIED: DP 1.2 Cable is VESA certified for guaranteed performance and compatibility, ensuring reliable signal consistency and smooth video playback on any DP display; Backward compatible with earlier DP versions
- QUALITY CONSTRUCTION: Nickel-plated latching DP connectors enable a precise fit and prevents accidental disconnections; Aluminum mylar shield for enhanced EMI protection; Durable TPE Jacket and strain reliefs are halogen-free and RoHS compliant
- APPLICATIONS: Ideal for 4K UHD displays; Up to 144Hz refresh rate at 1440p resolution; Suitable for high performance GPUs and workstations; Supports MST multi-monitor daisy chains; Connect a DP monitor to a 4K docking station
- SPECS: White; 10-foot (3-meter); VESA Certified DisplayPort 1.2; Supports HBR2/MST/HDCP 1.3; 4K 60Hz/1440p 144Hz/1080p 240Hz; 21.6Gbps; 8-ch Audio; Backward Compatible w/DP 1.1; 28AWG; 7.5mm (0.3in) O.D.
Specifications
Connector(s)
Connector A
1 - DisplayPort (20 pin, Latching)
Connector B
1 - DisplayPort (20 pin, Latching)
Environmental
Operating Temperature
0°C to 50°C (32°F - 122°F)
Storage Temperature
-20°C to 70°C (-4°F - 158°F)
Humidity
5% to 85%
Hardware
Active or Passive Adapter
Passive
Number of Conductors
19
Connector Plating
Nickel
Cable Jacket Material
TPE - Thermoplastic Elastomers
Cable Shield Material
Aluminum-Mylar Foil with Braid
Fire Rating
VW-1
Packaging Information
Package Height
0.8 in [2.0 cm]
Package Length
8.7 in [22.0 cm]
Shipping (Package) Weight
6.9 oz [196.0 g]
Package Width
7.9 in [20.0 cm]
Performance
Maximum Data Transfer Rate
21.6Gbps
Maximum Digital Resolutions
4K 60Hz
Audio Specifications
DisplayPort - 7.1 Channel Audio
Physical Characteristics
Color
White
Product Height
0.5 in [1.3 cm]
Product Length
6.1 ft [1.9 m]
Weight of Product
6.5 oz [184.0 g]
Product Width
0.8 in [2.1 cm]
Connector Style
Straight
Wire Gauge
28 AWG
Material
ABS
Cable Length
10.0 ft [3.1 m]
Cable OD
0.3 in [7.5 mm]
What's in the Box
Included in Package
1 - 10ft DisplayPort Cable - White
