FUSION APOLLO MARINE ENTERTAINMENT SYSTEM WITH BUILT-IN WI-FI RA770
- Brand: FUSION
- MPN: 010-01905-00
- Part #: CARFSN1009

Product URL: https://www.pbtech.com/au/product/CARFSN1009/FUSION-APOLLO-MARINE-ENTERTAINMENT-SYSTEM-WITH-BUI
Features
THE SUM OF AUDIO INNOVATION
The world's first touchscreen marine stereo with the AirPlay® 2 software feature and built-in Wi-Fi® connectivity, Apollo RA770 has redefined audio excellence with revolutionary technology and innovative design.
DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS
Built on the True-Marine design philosophy from Fusion®, the Apollo RA770 stereo has an IPX6- and IPX7-rated water-resistant front panel and has been tested to a high level of protection against salt fog, temperature, vibration and UV.
MODERN DESIGN AND AESTHETICS
Providing uniformity across the helm, the brilliantly designed black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy, uniform and elegant installation.
Specifications
General
Physical dimensions
Stereo dimensions (H x W x D) 82 x 192 x 119.4 mm
Weight
750 g
Water rating
IPX6 and IPX7 (front panel only, when properly installed)
Power input
10.8-16 VDC
Operating temperature range
0° to 50° C
Current (max.)
15 A
NMEA 2000 LEN
1 (50 mA)
Bluetooth wireless range
Up to 10 metres
ANT wireless range
Up to 3 metres
Wireless frequencies/protocols
Wi-Fi 2.4 GHz @ +15 dBm nominal
Bluetooth 2.4 GHz @ +10 dBm nominal
ANT 2.4 GHz @ +4 dBm nominal
Compass-safe distance
150 mm
Stereo features
Display
4.3-inch capacitive touch glass colour LCD
Built-in amplifier
Class-D (2 Ohm stereo-stable)
Peak power
280 W
Rated power output (2 Ohm)
43 W rms x 4 @ 14.4 V input < 10% THD
Rated power output (4 Ohm)
26 W rms x 4 @ 14.4 V input < 10% THD
Built-in Digital Signal Processing
Yes (with preconfigured DSP profiles)
PartyBus™-Network capabilities
Yes (wired or wireless)
Fusion-Link™ control
Yes (with MFD, smartphone and Garmin watch)
Multi-Zone™ technology
4 zones
Built-in Wi-Fi
Yes
Bluetooth wireless technology
Yes
ANT wireless technology
Yes
SiriusXM-ready
Yes (requires SiriusXM Connect vehicle tuner)
DAB+ ready
Yes (requires DAB100A antenna module)
Optical audio input
Yes
NRX remote compatibility
Yes
Multi-language interface
Bulgarian / Chinese (Simplified) / Chinese (Traditional) / Croatian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Italian / Japanese / Korean / Norwegian / Polish / Portuguese (BR) / Portuguese (PT) / Slovenian / Spanish / Swedish / Thai / Turkish
Software updates
Over-the-air software updates via the Fusion-Link app, USB
Sources
Sources
AM / FM / Bluetooth / Apple AirPlay 2 / digital optical input / USB audio / iPhone / iPod / AUX x2 / UPnP / MTP / SiriusXM-Ready (USA only, requires optional SiriusXM Connect vehicle tuner) / DAB+ ready (available in Europe and Australia only)
Connectivity
Auxiliary input
Two RCA inputs (AUX1, AUX2)
Optical audio input
One digital optical input (SPDIF) port
Ethernet
One Ethernet port
NMEA 2000
One NMEA 2000 port
USB 2.0
One USB 2.0 port
SiriusXM satellite radio
One SiriusXM port (requires SiriusXM Connect vehicle tuner; does not support traffic and weather)
M/FM radio
One Motorola antenna connector port
Speaker
4 x speaker connections (2 zone amplified)
RCA pre-out (left, right and subwoofer)
4 zones (requires external amplification)
Line out
4 (1 x L + R per zone, requires external amplification)
Subwoofer out
1 x mono output (requires external amplification)
