FUSION SM-F65CW SHALLOW MOUNT SPEAKER 6.5"- CLOTH BLACK
- Brand: FUSION
- MPN: 010-02263-11
- Part #: CARFSN1122

Product URL: https://www.pbtech.com/au/product/CARFSN1122/FUSION-SM-F65CW-SHALLOW-MOUNT-SPEAKER-65--CLOTH-BL
Features
The new Fusion SM Series shallow mount speakers, designed for installations where mounting depth is limited without compromizing on sound quality and performance. The SM Series speakers are engineered with a sealed, perfectly-tuned enclosure to deliver quality audio reproduction that normally could not be achieved from the limitations of shallow mounting depths.
Available in two colors (black or white), the SM Series speakers are a stylish addition to your vessel with its clean aesthetics and unique shallow mount form factor.
Shallow Basket Design
With a shallow mounting depth of only 24mm [15/16"], the SM Series speakers are ideal for installation where mounting depth is limited.
Tuned, Sealed Enclosure Design
Protects the speakers' components from damage and ensures quality audio reproduction is delivered that normally could not be achieved by a speaker with such a shallow design.
Retrofittable
The SM Series speakers have a circular back with a mounting diameter clearance of 130mm [5-1/8"], allowing it to fit easily into existing 6.5" speaker cutouts.
Aesthetic Interior Design
Designed with aesthetics in mind, the SM Series come with a high-end acoustic fabric grille and feature rounded edges and contour cues to add style to your vessel.
IP65 Weatherproof
The SM Series speakers are rated IP65 for protection against dust and water ingress in the harsh marine environment.
Specifications
Speaker Enclosure Size
155mm x 155mm [6-1/8" x 6-1/8"]
Peak Power Rating
100 Watts
Driver Size
Tuned and optimised 3"
Efficiency (1W/1M)
84 dB
Frequency Response
150 Hz - 20 kHz
Nominal Impedance
4 Ohms
Cone / Surround Material
Polypropylene with rubber surround
Mounting Diameter Clearance
130mm [5-1/8"]
Mounting Depth Clearance
24mm [15/16"]
Operating Temperature Range
0 to 50°C (32 to 122°F)
Storage Temperature Range
-20 to 70°C (-4 to 158°F)
Water and Dust Resistance (IPX rating)
IP65
Colour
Black
