BlackVue DR770X-2CH-TRUCK-LTE 64GB Truck Front & Commercial Rear Camera SIM Card Input

PB Tech price

$ 754 .47

+GST

$ 829 .92

inc GST

BlackVue DR770X-2CH-TRUCK-LTE 64GB Truck Front & Commercial Rear Camera SIM Card Input

Brand: BlackVue
MPN: DR770X-2CH-TRUCK-LTE
Part #: CARVUE1040
UPC:

PB Tech price

$ 829 .92

inc GST

+GST inc GST

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 09 Sep

Express Delivery Times

Metro - Within 2-3 working days

Rural - Within 3-5 working days

Standard Delivery Times

NSW, VIC, ACT, QLD - Within 3-7 working days

SA, WA, TAS, NT - Within 5-10 working days

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: BlackVue
MPN: DR770X-2CH-TRUCK-LTE
Part #: CARVUE1040
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

BLACKVUE DR770X-2CH LTE TRUCK FRONT & COMMERCIAL REAR CAMERA SIM CARD INPUT 64 GB

The DR770X-2CH TRUCK LTE is a Cloud dash cam with built-in LTE and waterproof rear camera. The rear camera is connected by a 15-meter (49ft) video cable so you can mount it externally on a variety of trucks and heavy vehicles. Best image quality night and day with Full HD Sony STARVIS™ image sensors front and rear. Easy Cloud connectivity with built-in Nano SIM card reader*, making it a dash cam of choice for commercial vehicle protection and fleet tracking.
Effortless set up with the BlackVue App.
(*) Data plan not included. BlackVue SIM card included in select models.

A truck dashcam built for the cloud

- Built-in 4G LTE connectivity makes connecting to the cloud hassle-free.
- Dual Full HD 1080p camera (front 60 / rear 30 frames per second) provide fluid videos of the front and back of your vehicle.
- View angle: front camera 139 degrees; rear camera: 116 degrees.
- STARVIS imaging sensors- a reference in video clarity under low light-equip both front and rear camera, so whether you are driving or parked, crucial details are captured perfectly.

Infrared external rear camera

- With rugged metal casting
- With its metal waterproof casing the rear camera of the DR770X-2CH-TRUCK is built to withstand most weather conditions. Its ingress protecting rating (IP69K) means it can even withstand power washing. It is designed to be installed at the rear of trucks or heavy vehicles. We recommend securing it in the place on a flat surface using the provided screws. The luminosity sensor detects ambient brightness and automatically activates the six infrared lights to help identify vehicles and objects in the dark.

Specifications

Model Name

DR770X-2CH Truck LTE

Channel

2CH

Product Dimensions

Front: Black / Width 137.6mm x Height 43mm / 161g
Rear: Black / Width 70.4mm x Height 36mm / 157g

Rear Camera Connection

Coaxial cable

Memory Support

microSD card up to 512GB

Recording Modes

Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
* When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.

Parking Mode

YES (hardwiring cable included)

Parking Mode Event Voice Notifications

YES

Imaging Sensor

Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)

Viewing Angle

Front: Diagonal 139°, Horizontal 116°, Vertical 61°
Rear: Diagonal 116°, Horizontal 97°, Vertical 51°

Resolution Frame Rate

Front: Full HD (1920×1080) @ 60 fps
Rear: Full HD (1920×1080) @ 30 fps
* Frame rate may vary during Wi-Fi streaming.

Video Codec

H.264 (AVC)

Image Quality and Bitrate Front/Rear

Highest (Extreme): 25+10 Mbps
Highest: 12+10 Mbps
High: 10+8 Mbps
Normal: 8+6 Mbps

Format Free

YES (Adaptive)

Event File Overwrite Protection

YES (up to 50)

SD Card Failure Alert

YES

Scheduled Reboot

YES

Video File Extension

MP4

Wi-Fi

Built-in (802.11n (2.4~2.4835 GHz))

Cloud Compatible

YES

GPS

Built-in

Microphone

Built-in

Speaker

Built-in

Impact Sensor

3-Axis Acceleration Sensor

Rear Camera IR Illumination

940 nm (4 Infrared (IR) LEDs)

Operation Temperature

-20- 70 (-4°F - 158°F)

Storage Temperature

-20 - 70 (-4°F - 158°F)

High Temp Cut Off

Approx. 80 °C (176 °F)

Backup Battery

Built-in supercapacitor

Input Power

DC 12V-24V (3 pole DC Plug(Ø3.5d x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)

Power Consumption Hour

Normal Mode (GPS On/Cloud On) : Avg. 470mA/12V
Normal Mode (GPS On/Cloud Off) : Avg. 410mA/12V
Parking Mode (GPS Off/Cloud On) : Avg. 370mA/12V
Parking Mode (GPS Off/Cloud Off) : Avg. 310mA/12V
* Approx. 60mA increase in current when IR LEDs are ON.
* Actual power consumption may vary depending on use conditions and environment.
* Model DR770X-2CH Truck LTE should be used only in circuits that satisfy Limited Power Source.
(Maximum power consumption is to be less than 100 VA or 8 A).)

Manufacturer Part No:

DR770X-2CH-TRUCK-LTE

Brand:

BlackVue

Product Type:

Truck Front & Commercial Rear Camera

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

CARVUE1040

Product Model:

DR770X-2CH-TRUCK-LTE

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
