HiLook NVR-232MH-K-16P 32 Channel 1U 4K Network Video Recorder with 4TB HDD
16-Port PoE - Max Power budget 200W - Supports up to 2x 10TB HDD
HiLook NVR-232MH-K-16P 32 Channel 1U 4K Network Video Recorder with 4TB HDD
16-Port PoE - Max Power budget 200W - Supports up to 2x 10TB HDD
- Brand: HiLook
- MPN: NVR-232MH-K-16P
- Part #: CCTHLK1033
- UPC:
View all shipping info
- Brand: HiLook
- MPN: NVR-232MH-K-16P
- Part #: CCTHLK1033
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Network Video Recorders





HiLook NVR-232MH-K-16P 32 Channel 1U 4K Network Video Recorder with 4TB HDD 16-Port PoE - Max Power budget 200W - Supports up to 2x 10TB HDD
- Brand: HiLook
- MPN: NVR-232MH-K-16P
- Part #: CCTHLK1033

Product URL: https://www.pbtech.com/au/product/CCTHLK1033/HiLook-NVR-232MH-K-16P-32-Channel-1U-4K-Network-Vi
Features
- Up to 32-ch IP camera inputs, plug & play with 16 power-over-Ethernet (PoE) interfaces
- H.265+/H.265/H.264+/H.264 video formats
- Up to 2-ch@ 12 MP or 3-ch@ 8 MP or 6-ch@ 4 MP or 12-ch@ 1080p decoding capacity
- Up to 256 Mbps incoming bandwidth
Professional and Reliability
- H.265+ compression effectively reduces the storage space by up to 75%
- Adopt stream over TLS encryption technology which provides more secure stream transmission service
HD Video Output
- Provide independent HDMI and VGA outputs
- HDMI video output at up to 4K resolution
Storage and Playback
- Up to 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
- 16-ch synchronous playback
Network & Ethernet Access
- 16 independent PoE network interfaces
- 1 self-adaptive 10/100/1000 Mbps Ethernet interface
- HiLookVision for easy network management
Specifications
Video and Audio
IP Video Input
32-ch
Incoming Bandwidth
256 Mbps
Outgoing Bandwidth
160 Mbps
HDMI Output
1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode
HDMI/VGA independent output
CVBS Output
N/A
Audio Output
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Two-Way Audio
1-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding Format
H.265/H.265+/H.264+/H.264
Recording Resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback
16-ch
Decoding Capability
2-ch@ 12 MP (30 fps)/3-ch@ 8 MP (30 fps)/6-ch@ 4 MP (30 fps)/12-ch@ 1080p (30 fps)
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726/AAC
Network
Remote Connection
128
ΑΡΙ
ONVIF (profile S/G); SDK; ISAPI
Compatible Browser
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, ISCSI, ISUP, UPnPTM, HTTP, HTTPS
Network Interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
POE
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 200 W
Standard
IEEE 802.3af/at
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 10 TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
AlarmIn/Out
4/1
General
GUI Language
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Power Supply
100 to 240 VAC, 50 to 60 Hz
Consumption
≤ 15 W (without HDD and PoE off)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
Weight
≤ 3 kg (without HDD, 6.6 lb.)
