Milesight EM300-SLD-868M LoRaWAN EU868/IN865 EM300 Spot Leakage Detection IoT Sensor
- Brand: Milesight
- MPN: EM300-SLD-868M
- Part #: CCTMLS1043

Product URL: https://www.pbtech.com/au/product/CCTMLS1043/Milesight-EM300-SLD-868M-LoRaWAN-EU868IN865-EM300
Features
Milesight LoRaWAN EU868/IN865 EM300 Spot Leakage Detection IoT Sensor
Milesight LoRaWAN EU868/IN865 EM300 Spot Leakage Detection IoT Sensor. The Milesight EM300-SLD is a compact spot leakage detection LoRaWAN IoT sensor for detecting the presence of water (or other liquids) and transmitting an alarm using LoRaWAN® technology. With its low power consumption technology, the EM300-SLD can work up to 5 years with one 4000 mAh battery. Combining a Milesight LoRaWAN® gateway and Milesight IoT Cloud solution, users can manage all their sensor data remotely and visually and receive alarms via a mobile APP.
The EM300-SLD also integrates a temperature and humidity sensor, which perfect for applications such as pipe leak monitoring, basement flooding, pump failure, etc.
- Detect the presence of liquids by a small water probe based on conductivity
- Embedded with temperature and humidity sensors for environment monitoring
- Ultra-wide-distance transmission up to line of sight of 10km
- IP67 UV-resistant and waterproof enclosure for harsh environment applications
- Built-in 4000 mAh replaceable battery and works for 5 years without replacement
- Equipped with NFC for easily configuration
- Compliant with standard LoRaWAN® gateways and network servers
- Quick and easy management with Milesight IoT Cloud solution
Advanced Alarm Settings
With customized alarm report interval and times, users are able to apply it flexibly in various scenarios.
3 Sensors in 1
EM300-SLD/ZLD is equipped with temperature and humidity sensors for comprehensive monitoring in one device.
- Temperature: + 0.3°C (0°C ~ 70°C), + 0.6°C (-30°C ~ 0°C)
- Humidity: + 3% (10% ~ 90%), + 5% (below 10% and above 90%)
Industrial Grade Design for Harsh Environment
- IP67 Enclosure for Dust and Water Ingress
- UV Resistance
LoRaWAN® Based
- Penetrating Signals: data transmission range up to 2 km in urban areas and 15 km in rural areas
- High Compatibility: compliant with standard LoRaWAN® gateways and network servers
Specifications
Product Code
EM300-SLD-868M
Frequency
IN865/RU864/EU868
Tx Power
16dBm
Sensitivity
-147dBm @300bps
Mode
OTAA/ABP Class A
Trigger Condition
When liquid level reaches 5mm
Cable Length
1.5m (customizable)
Temperature Range
-30°C to + 70°C
Accuracy
0°C to + 70°C (+/- 0.3°C), -30°C to 0°C (+/- 0.6°C)
Humidity Range
0% to 100% RH
Accuracy
10% to 90% RH (+/- 3%), below 10% and above 90% RH (+/- 5%)
Resolution
0.5% RH
Power
On & Off NFC, power button (Internal)
Configuration
Mobile APP(via NFC) or PC software (via USB Type-C)
Power Supply
1 × 4000 mAh ER18505 Li-SOCL2 battery (extendable to 2 batteries)
Battery Life*
>5 years (10 min interval and alarm once every day, SF10)
Operating Temperature
-30°C to +70°C
Relative Humidity
0% to 100% (non-condensing)
Ingress Protection
IP67
Dimension
105.6 × 85.3 × 27 mm (4.16 × 3.36 × 1.06 in)
Installation
Wall Mounting
Package Contents
Sensor, Mounting screws, Warranty card, Quick start guide
