Ubiquiti UniFi Access Reader Lite (UA-Reader Lite)
- Brand: Ubiquiti
- MPN: UA-Reader-Lite
- Part #: CCTUBI8225
- UPC:810010076816

Product URL: https://www.pbtech.com/au/product/CCTUBI8225/Ubiquiti-UniFi-Access-Reader-Lite-UA-Reader-Lite
Features
UniFi® Access Reader Lite is a modern NFC and Bluetooth reader, a part of the UniFi Access solution.
The UniFi Access Reader Lite has been designed for convenient use and secure access. The PoE powered reader is easy to install and supports the latest NFC security standards including AES-128 encrypted MIFARE DESFire. Unlocking the door is quick and secure with NFC card or with mobile app.
- Elegantly designed NFC and Bluetooth reader
- 802.3af PoE powered by UniFi Access Hub
- Advanced NFC credentials, including MIFARE DESFire
- Built-in security element chip
- For the best NFC security, use with our UA-Card
- Mobile access with app (future software release)
Works with the UniFi Access Application
Centrally manage your Access devices with one intuitive interface
Set door, floor, and user-specific access policies and schedules
Create users, set their roles, and assign NFC cards
Review entries, exits, and denials with detailed event logging
Set up devices quickly and manage them on the go with a powerful mobile app
Specifications
Mechanical
Dimensions
94.91 x 40.00 x 31.10 mm (3.74 x 1.57 x 1.22")
Weight
67 g (2.36 oz)
Enclosure material
Polycarbonate
Mounting options*
Wall-mount, gang box mount*
*The UA-Reader Lite must be installed either indoors or under a roof eave outdoors.
Weatherproofing
IP54
Hardware
Networking interface
10/100 MbE
Max. power consumption
6W
Power method
PoE
Button
(1) Factory reset
LEDs
White/Blue
Connectivity
Ethernet, BLE 4.1
NFC frequency
13.56 MHz
NFC reading range
<30 mm
NFC standards
ISO 14443A, 14443B, 15693
NFC technology
NFC Tag 1, 2, 3, 4, 5
MIFARE Classic
MIFARE Plus
MIFARE Ultralight
MIFARE DESFire
Operating temperature
-20 to 40° C (-4 to 104° F)
Operating humidity
5 to 90% noncondensing
Certifications
CE, FCC, IC
