MSI MAG PANO 110R PZ White Mini Tower for ATX/MATX Tempered Glass with 4x120mm ARGB Fans Pre-installed, CPU Cooler Support Upto 160mm, GPU Support Upto 400mm, 7x PCI Slot, 360mm Radiator Supported, Front I/O: 1x Type C, 2x USB, HD Audio
Out of stock
MSI MAG PANO 110R PZ White Mini Tower for ATX/MATX Tempered Glass with 4x120mm ARGB Fans Pre-installed, CPU Cooler Support Upto 160mm, GPU Support Upto 400mm, 7x PCI Slot, 360mm Radiator Supported, Front I/O: 1x Type C, 2x USB, HD Audio
- Brand: MSI
- MPN: MAG PANO 110R PZ WHITE
- Part #: CHAMSI0051
- UPC: 824142396339
View all shipping info
What PB Tech customers are saying about this product...
See More Reviews"Almost went for a popular Lian Li mini tower case, but after seeing that there is zero cable management, and no fans included I stumbled on this MSI case. Four fans included and pr ...view more"
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Cases / Chassis





MSI MAG PANO 110R PZ White Mini Tower for ATX/MATX Tempered Glass with 4x120mm ARGB Fans Pre-installed, CPU Cooler Support Upto 160mm, GPU Support Upto 400mm, 7x PCI Slot, 360mm Radiator Supported, Front I/O: 1x Type C, 2x USB, HD Audio
- Brand: MSI
- MPN: MAG PANO 110R PZ WHITE
- Part #: CHAMSI0051
- UPC:824142396339

Product URL: https://www.pbtech.com/au/product/CHAMSI0051/MSI-MAG-PANO-110R-PZ-White-Mini-Tower-for-ATXMATX
Features
MAG PANO 110R PZ WHITE
- 270-Degree Display: The chassis features a 270-degree panoramic design with tempered glass, providing an expansive view to showcase detailed components.
- Measurements: Supports multiple motherboard sizes, including regular ATX, Micro-ATX, Mini-ITX and back-connect ATX and Micro-ATX, allowing users to customize their PC setup.
- Pre-build with Reverse Blades Fan: Pre-installed reverse blade fans on the side ensure an unobstructed display of the ARGB fan's lighting effects, free from interference by fan frames.
- ARGB-Fan Control Board: The 1-to-5 ARGB fan control board supports up to 5 ARGB fans, allowing users to adjust 18 ARGB lighting effects with a single LED switch button
- Upgrade Airflow Layout: Supports up to 10 fans, a 360mm radiator on top and a 120mm radiator at rear. The lower chamber, surrounded by vents, further enhances heat dissipation for optimal performance.
MAG - MSI ARSENAL GAMING
MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
To fulfill the desire for showcasing an ARGB PC build, the MAG PANO 110R Series features a 270-degree panoramic display, enhancing aesthetics and maintaining a clean design.
Decorated with a metal nameplate to highlight the MAG family identity.
Featuring a 1-to-5 ARGB fan control hub, this system is fully compatible with MSI Mystic Light, allowing for easy sync and customizable ARGB lighting effects.
Pre-installed with 3 x ARGB reverse blade fans at the side and 1 x ARGB fan at the rear for optimal airflow and a clean, stylish design.
AIRFLOW OPTIMIZATION
Increase the number of vents on the sides and front of the case to enhance overall heat dissipation.
COOLING SUPPORT
Fans
Radiator
REMOVABLE GLASS PANEL
Screwless mounting and tool-free removable panel design on both sides allow for greater setup flexibility.
OPTIMAL AIRFLOW AND CLEANLINESS
The case has 2 removable filters on top and bottom sides, protecting internal components from dust accumulation.
1-5 ARGB FAN CONTROL HUB
The fan control board supports 5 ARGB PWM fans, offers 18 lighting modes controlled via an LED button, and ensures stability with power through SATA and easy cable management.
EZ TO INSTALL
The uni-front-panel cable is easy for users to connect to MSI motherboards.
Push-latch side panel and PCIe bracket, streamline installation process, enhancing the experience.
COMPONENTS COMPATIBILITY
Motherboard Support:
Regular: ATX / Micro-ATX / Mini-TX
Back-connect: ATX / M-ATX
CPU cooler maximum height:
< 160 mm
GPU maximum length:
< 400 mm
Power supply:
< 200 mm
Storage Support
Connectable Front I/O
1. USB 20Gbs (Type-C)
2. USB 5Gbs (Type-A) x 2
3. Mic In/ Audio Out
4. LED Switch Button
5. Power Button
Specifications
Product Name
MAG PANO 110R PZ WHITE
Case Form Factor
Mid-Tower
Motherboard Form Factor Support
Regular:
ATX / Micro-ATX / Mini-ITX
Back-connect:
ATX / Micro-ATX
I/O Ports
1 x USB 20Gbs (Type-C)
2 x USB 5Gbs (Type-A)
1 x Audio-Out / Mic-in
1 x LED Button
1 x Power Button
Drive Mount Support
2 x 2.5"
2 x 3.5"
2 x 2.5"/3.5" combo
Expansion Slots
7
Maximum GPU Length
400 mm / 15.75 inches
Maximum CPU Cooler Height
160 mm / 6.30 inches
Power Supply Support
ATX
Maximum PSU Length
200 mm / 7.87 inches
Fan Size Support
Top: 3 x 120 mm / 2 x 140 mm
Front: NA
Rear: 1 x 120 mm
Side: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm (Above the power shroud)
Pre-installed Fan Size
Side: 3 x 120 mm
Rear: 1 x 120 mm
Pre-installed Fan Type
Side: 3 x ARGB Fan (Reverse Blades Fan)
Rear: 1 x ARGB Fan
Radiator Size Support
Top: 120 / 140 / 240 / 280 / 360 mm
Front: NA
Rear: 120 mm
Side: NA
Bottom: NA
Dimensions (DxWxH)
420 x 225 x 485 mm / 16.54 x 8.86 x 19.09 inches
